Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 75mm -
Fork SunTour
-
Groupset Tourney -
Suspension Hardtail -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Storm 27.5" Alloy XC Frame
Suspension Fork
Suntour M3030 27.5 75mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney RD-TX55
Front Derailleur
Shimano Tourney FD-TX50
Shift Levers
Shift housing - Black
Cassette
Sunrace 11-34T
Crank
Shimano Tourney FC-M131 42/34/24T - Black
Bottom Bracket
Cartridge BB
Chain
KMC Z-50
Chain Tensioner
N/A
Pedals
Black Resin
Wheels
Front Hub
Joytech 751DSE Alloy QR
Rear Hub
Joytech 702TSE Alloy QR 9spd
Rims
Norco Alloy DW 27.5"
Tires
N/A
Brakes
Brakes
Tektro 837AL v-brakes black
Brake Levers
Shimano Easy-Fire 51 w/2-finger levers
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy 80mm
Handlebar
Norco Alloy 680mm/25mm 31.8
Grips
Norco Grip
Headset
FSA No. 10P w/15mm conical spacer - Black
Seat
Saddle
Norco XC Saddle
Seatpost
Norco Alloy 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.82 mm | 1.76 mm | 1.69 mm | 1.62 mm | 1.56 mm | 1.5 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 300 mm | 300 mm | 300 mm |
| Front Center | 600 mm | 618 mm | 642 mm | 666 mm | 688 mm | 711 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 43 mm | 42 mm |
| Trail | 95 mm | 93 mm | 91 mm | 90 mm | 87 mm | 86 mm |
| Stack | 596 mm | 607 mm | 617 mm | 627 mm | 638 mm | 648 mm |
| Reach | 327 mm | 344 mm | 366 mm | 388 mm | 409 mm | 431 mm |
| Top Tube Length | 506 mm | 531 mm | 561 mm | 591 mm | 621 mm | 651 mm |
| Seat Tube Angle | 73.5 ° | 73.1 ° | 72.7 ° | 72.3 ° | 71.9 ° | 71.5 ° |
| Seat Tube Length | 340 mm | 390 mm | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 68.5 ° | 68.75 ° | 69 ° | 69.25 ° | 69.5 ° | 69.75 ° |
| Head Tube Length | 125 mm | 135 mm | 145 mm | 160 mm | 170 mm | 180 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1020 mm | 1039 mm | 1062 mm | 1087 mm | 1110 mm | 1132 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 722 mm | 715 mm | 724 mm | 767 mm | 775 mm | 785 mm |
| Front Travel | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" |
Model Overview
Storm 7.4 completes the Norco Storm model. 177 bikes variations carry this model name so far. You can get a glimpse at all models from 2016, by clicking on this link.
Model range prices
Norco Storm 2.3 2016 is the cheapest bike model and costs 285$. Norco Storm 7.1 2016 is the most expensive one and costs 675$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2016 for 429$. In conclusion, this bike price is 344.06% lower than the price of the average Crosscountry bike.
Overview of components
Fork
The Storm 7.4 comes factory-installed with the SunTour fork. This has a travel range of 75mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When it comes to wheels, the Storm 7.4 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
