Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Storm Alloy XC
Suspension Fork
Suntour XCM 29 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Acera RD-M390 9spd
Front Derailleur
Shimano Altus 3spd
Shift Levers
Jagwire
Cassette
Shimano CS-HG20 11/34 9spd
Crank
Suntour XCM 44/32/22
Bottom Bracket
Cartridge BB
Chain
SRAM PG951 9spd
Chain Tensioner
N/A
Pedals
Wellgo Resin Pedals
Wheels
Front Hub
SRAM MTH-306
Rear Hub
SRAM MTH-306
Rims
Alex TD26 D/W
Tires
Impac Ridgepac 29"x 2.1 tires"
Brakes
Brakes
Shimano M395 Hydraulic 160mm
Brake Levers
Shimano Deore BL-M395
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy
Handlebar
Norco Alloy 15mm Riser 680mm
Grips
Norco Grip
Headset
FSA No. 10P w/15mm conical spacer Black
Seat
Saddle
Norco XC Saddle
Seatpost
Norco Alloy 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 18.5" | 20" | 21.5" | 23" |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.73 mm | 1.69 mm | 1.61 mm | 1.55 mm | 1.51 mm | 1.48 mm |
| Bottom Bracket Height | 302 mm | 302 mm | 307 mm | 307 mm | 307 mm | 307 mm |
| Front Center | 621 mm | 629 mm | 650 | 670 mm | 684 mm | 698 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Stack | 626 mm | 633 mm | 633 mm | 638 mm | 642 mm | 647 mm |
| Reach | 362 mm | 374 mm | 394 mm | 412 mm | 425 mm | 437 mm |
| Top Tube Length | 548 mm | 568 mm | 588 mm | 608 mm | 628 mm | 648 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 381 mm | 432 mm | 470 mm | 508 mm | 546 mm | 584 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 115 mm | 120 mm | 125 mm | 130 mm | 135 mm | 140 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1060 mm | 1068 mm | 1091 mm | 1111 mm | 1125 mm | 1139 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 784 mm | 778 mm | 781 mm | 797 mm | 813 mm | 831 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 24" | 24" | 24" | 24" | 24" | 24" |
Model Overview
Storm 9.1 is part of the Norco Storm model. There are 177 bikes that carry this model name. Take a sneak peek at all Norco Storm bikes models from 2014, by clicking here.
Model range prices
Norco Storm 6.3 Forma 2014 is the cheapest bike model and costs 420$. Norco Storm 7.1 Forma 2014 is the most expensive one and costs 685$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Mountain bikes average price
If you want an acceptable Mountain bike you should know that the average price is 616$. However, even if your budget is less than the average, you might still be able to get a top-quality Mountain bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2014 and its price was 685$. Comparing the average cost of a Mountain bike to this one, you will see that Storm 9.1 price is 11.2% higher.
Storm 9.1 components
Fork
The fork installed on this bike is the SunTour XCM model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When leaving the production line, the Storm 9.1 model has 24″ aluminum wheels. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
