Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 100mm -
Fork SunTour XCM HLO
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Storm 29" Alloy XC Frame"
Suspension Fork
Suntour XCM HLO 29 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Alivio 9spd
Front Derailleur
Shimano Altus 3spd
Shift Levers
N/A
Cassette
Shimano CS-HG200 11/34 9spd
Crank
Suntour XCM 40/30/22
Bottom Bracket
Cartridge BB
Chain
KMC Z99 9spd
Chain Tensioner
N/A
Pedals
Feimin Alloy
Wheels
Front Hub
Joytech D341DSE Alloy Disc QR
Rear Hub
Joytech D342TSE-HL Alloy Disc QR 9spd
Rims
Alex Alloy DW Disc 29""
Tires
WTB Nineline 29"x2.25"
Brakes
Brakes
Tektro Auriga Hydraulic 160mm
Brake Levers
Tektro Auriga
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy 80mm
Handlebar
Norco Alloy 15mm riser 720mm
Grips
Norco Grip
Headset
N/A
Seat
Saddle
Norco XC Saddle
Seatpost
Norco Alloy 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.69 mm | 1.62 mm | 1.56 mm | 1.51 mm |
| Bottom Bracket Height | 303 mm | 308 mm | 308 mm | 308 mm |
| Front Center | 654 mm | 678 mm | 700 | 722 mm |
| Rake | 46 mm | 45 mm | 47 mm | 47 mm |
| Stack | 640 mm | 650 | 660 mm | 671 mm |
| Reach | 379 mm | 401 mm | 422 mm | 443 mm |
| Top Tube Length | 578 mm | 608 mm | 638 mm | 668 mm |
| Seat Tube Angle | 72.8 ° | 72.4 ° | 72 ° | 71.6 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 69.25 ° | 69.5 ° | 69.75 ° | 70 ° |
| Head Tube Length | 115 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1091 mm | 1116 mm | 1139 mm | 1161 mm |
| Bottom Bracket Drop | 68 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 742 mm | 788 mm | 794 mm | 805 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 24" | 24" | 24" | 24" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Storm 9.1 is a Norco Storm model. 177 bikes variations carry this model name so far. Take a sneak peek at all Norco Storm bikes models from 2017, by clicking here.
Model range prices
Norco Storm 7.4 Forma Step-Thru 2017 is the most affordable bike of this model and has a price of 429$. On the other hand, Norco Storm 7.1 2017, is the most expensive and costs 639$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Mountain bikes
According to our calculations, the average cost of a Mountain bike that is reliable is 616$. However, this doesn’t mean that if you spend less money on a Mountain bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2017 for 639$. Doing a quick comparison, we notice that Storm 9.1 price is 3.73% more expensive than the average cost of a Mountain bike.
Overview of components
Fork
Norco Storm 9.1 2017 bike is equipped with the SunTour XCM HLO fork, and has 100mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the Storm 9.1 bike is equipped with the 24″ aluminum model. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Storm 9.1 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Storm 9.1 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
