Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset 105, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Threshold Cross Double Butted Alloy - Disc
Suspension Fork
Carbon Bladed w/Tapered Alloy Steer - Disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105 RD-5701 - Black
Front Derailleur
Shimano 105 FD-5700L - Black
Shift Levers
Casing w/Mini In-Line Adjusters - White
Cassette
Shimano CS-4600 12-28T 10 speed
Crank
FSA Gossamer CK-C6020SS 46/36T - Black
Bottom Bracket
FSA MegaExo BB-4400
Chain
SRAM CN-PC1031 10speed
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Shimano Deore 6 bolt Disc - Black
Rear Hub
Shimano Deore 6 bolt Disc - Black
Rims
WTB SX17 Disc 32H - Black
Tires
Vittoria Cross XG Pro 700x32c - Folding
Brakes
Brakes
Hayes CX-5 Mechanical Disc w/160mm rotor
Brake Levers
Shimano 105 ST-5700
Disk Rotors
N/A
Cockpit
Stem
Norco - Black w/Red
Handlebar
Norco Compact - Black w/Red
Grips
Norco Gel Wrap - Black
Headset
FSA No.42 Tapered
Seat
Saddle
Norco Cross Sport - Black
Seatpost
Norco - Black w/Red
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | - | - | - | - | - |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.44 mm | 1.48 mm | 1.49 mm | 1.51 mm |
| Bottom Bracket Height | 279.5 mm | 294 mm | 294 mm | 294 mm | 294 mm |
| Front Center | 589 mm | 590 mm | 594 mm | 609 mm | 621 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 74 mm | 67 mm | 62 mm | 59 mm | 58 mm |
| Stack | 541 mm | 540 mm | 561 mm | 582 mm | 602 mm |
| Reach | 364 mm | 374 mm | 378 mm | 391 mm | 400 mm |
| Top Tube Length | 510 mm | 530 mm | 545 mm | 565 mm | 585 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 480 mm | 530 mm | 560 mm | 590 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 72.3 ° | 72.8 ° | 73 ° |
| Head Tube Length | 120 mm | 125 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 425 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1003 mm | 1002 mm | 1005 mm | 1020 mm | 1033 mm |
| Bottom Bracket Drop | 72 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Threshold A1 is part of the Norco Threshold model. Norco released 58 bikes variations of this model so far. Check out the entire range from 2013 of this model, by clicking this link.
Model range prices
Norco Threshold A3 2013 is the most affordable bike of this model and has a price of 900$. On the other hand, Norco Threshold SL 2013, is the most expensive and costs 3625$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Cyclocross bikes average price
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, even though the average price of a Cyclocross bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Norco released this model in 2013, its price was 1525$. Doing a quick comparison, we notice that Threshold A1 price is 31.93% lower than the average cost of a Cyclocross bike.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Norco Threshold A1 2013, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
