Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Threshold Cross Double Butted Alloy - Disc
Suspension Fork
Norco X-Over Alloy Straight Blade - Disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Sora RD-3500 SS
Front Derailleur
Shimano Sora FD-3500
Shift Levers
Casing w/Mini In-Line Adjusters - Black
Cassette
Shimano CS-HG20 11-32T 9spd
Crank
Shimano Sora FC-3500 46/36 - Black
Bottom Bracket
Shimano HollowTech II
Chain
SRAM CN-PC951 9speed
Chain Tensioner
N/A
Pedals
Wellgo alloy body w/steel cage
Wheels
Front Hub
Alloy disc hub - Black
Rear Hub
Alloy cassette disc hub - Black
Rims
Double Wall Aluminum - Black
Tires
Continental CityRIDE II 32c w/ProTection
Brakes
Brakes
Hayes CX-5 Mechanical Disc w/160mm rotor
Brake Levers
Shimano Sora ST-3500
Disk Rotors
N/A
Cockpit
Stem
Norco - Black w/Blue
Handlebar
Norco Compact - Black w/Blue
Grips
Norco Wrap - Black
Headset
FSA No.11 Internal Semi-Cartridge
Seat
Saddle
Norco Cross Race - Black
Seatpost
Norco Alloy 27.2mm - Black w/Blue
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.54 mm | 1.56 mm | 1.57 mm | 1.6 mm |
| Bottom Bracket Height | 279.5 mm | 279.5 mm | 282 mm | 284.5 mm | 284.5 mm |
| Front Center | 589 mm | 592 mm | 601 mm | 611 mm | 620 mm |
| Rake | 46 mm | 45 mm | 45 mm | 45 mm | 46 mm |
| Trail | 73 mm | 71 mm | 67 mm | 64 mm | 60 mm |
| Stack | 550 mm | 562 mm | 580 mm | 598 mm | 619 mm |
| Reach | 361 mm | 365 mm | 372 mm | 381 mm | 388 mm |
| Top Tube Length | 510 mm | 527.5 mm | 545 mm | 565 mm | 585 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 510 mm | 540 mm | 570 mm | 600 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 120 mm | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1004 mm | 1007 mm | 1016 mm | 1027 mm | 1036 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 67 mm | 67 mm |
| Standover Height | 753 mm | 769 mm | 793 mm | 817 mm | 840 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Threshold A3 completes the Norco Threshold model. There are 58 bikes that carry this model name. You can easily view all of the Norco Threshold bikes models from 2014, here.
Model range prices
Norco Threshold A3 2014 is the most economical model, with a starting price of 860$. Norco Threshold SL 2014 on the other hand costs 5110$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Cyclocross bikes
If you want to purchase a solid Cyclocross bike, it is important to know that the average cost is 2012$. However, this doesn’t mean that if you spend less money on a Cyclocross bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Norco Threshold A3 price was 860$. Comparing the average cost of a Cyclocross bike to this one, you will see that Threshold A3 price is 133.95% lower.
Overview of components
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
As for the wheels, Norco Threshold A3 2014, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Threshold A3 has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
