Norco Threshold C Frame/Fork 2021
2021 Road
Estimate price |
1,699$
Bike details
Overview
Key information split into simple groups.
Frame summary
-
Category -
Frame Carbon -
Wheels 700c -
Suspension Rigid
Sizing
Recommended size guide.
48cm
152cm - 161cm
50.5cm
158cm - 167cm
53cm
165cm - 174cm
55.5cm
171cm - 180cm
58cm
177cm - 186cm
60.5cm
184cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Threshold Carbon
Suspension Fork
Norco Threshold Carbon
Drivetrain
Front Derailleur
Norco Integrated 1x Guide
Cockpit
Headset
FSA Orbit No. 42
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.44 mm | 1.47 mm | 1.48 mm | 1.49 mm | 1.51 mm |
| Bottom Bracket Height | 275 mm | 275 mm | 275 mm | 275 mm | 276.5 mm | 276.5 mm |
| Front Center | 593 mm | 597 mm | 597 mm | 603 mm | 616 mm | 628 mm |
| Rake | 51 mm | 51 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 71 mm | 68 mm | 66 mm | 62 mm | 60 mm | 58 mm |
| Stack | 518 mm | 532 mm | 548 mm | 565 mm | 583 mm | 603 mm |
| Reach | 365 mm | 369 mm | 374 mm | 381 mm | 390 mm | 399 mm |
| Top Tube Length | 505 mm | 517.5 mm | 532.5 mm | 550 mm | 567.5 mm | 585 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 480 mm | 505 mm | 530 mm | 555 mm | 580 mm | 605 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71.25 ° | 72 ° | 72.25 ° | 72.5 ° |
| Head Tube Length | 105 mm | 117.5 mm | 130 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 415 mm | 415 mm | 417 mm | 417 mm | 420 mm | 420 mm |
| Wheelbase | 998 mm | 1002 mm | 1005 mm | 1011 mm | 1027 mm | 1039 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 68 mm | 68 mm |
| Standover Height | 712 mm | 732 mm | 753 mm | 786 mm | 810 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 158 cm | 165 cm | 171 cm | 177 cm | 184 cm |
| Rider Max Height | 161 cm | 167 cm | 174 cm | 180 cm | 186 cm | 194 cm |
Model Overview
Threshold C Frame/Fork is part of the Norco Threshold model. Norco launched 58 frames of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Cyclocross frames average price
According to our calculations, the average cost of a Cyclocross frame that is reliable is 1405$. However, you could also get a good Cyclocross frame even if you pay a lower amount than the average price. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2021 for 1699$. Comparing this to the average Cyclocross frame price, we see that the price is 20.93% more expensive.
Overview of components
Fork material
Threshold C Frame/Fork has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Sizes
Threshold C Frame/Fork comes in 6 sizes, that range from 152 cm – 194 cm (4.99 ft – 6.36 ft). In conclusion, it won’t take much to find one that’s right for you.
