Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Rival 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Threshold Mid-Mod Carbon - TA Disc
Suspension Fork
Threshold Mid-Mod Full Carbon - TA Disc
Drivetrain
Rear Derailleur
SRAM Rival 1 Medium Cage
Front Derailleur
N/A
Shift Levers
N/A
Cassette
SRAM PG1130 11-32T
Crank
SRAM Rival 1 42T - Black
Bottom Bracket
SRAM PressFit30
Chain
SRAM PC1130
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
A-Class CXD4 Sealed Bearing - 15x100mm
Rear Hub
A-Class CXD4 Sealed Bearing - 12x142mm
Rims
A-Class CXD4 - Tubeless Ready Design
Tires
Clement Crusade MXP 700 x 33c - Folding
Brakes
Brakes
SRAM Rival 1 Hydraulic Disc w/160mm Rotor
Brake Levers
SRAM Rival 1 Hydraulic Disc
Disk Rotors
N/A
Cockpit
Stem
Norco - Black Stealth
Handlebar
Norco Compact - Black Stealth
Grips
Norco Ultra-Comfort 3mm - Black/Salmon
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco Cross Race - Black
Seatpost
Norco Composite 27.2 - UD Carbon Stealth
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.45 mm | 1.46 mm | 1.48 mm | 1.49 mm |
| Bottom Bracket Height | 282.5 mm | 282.5 mm | 282.5 mm | 282.5 mm | 282.5 mm |
| Front Center | 589 mm | 593 mm | 601 mm | 613 mm | 626 mm |
| Rake | 45 mm | 45 mm | 46 mm | 45 mm | 45 mm |
| Trail | 74 mm | 67 mm | 61 mm | 61 mm | 59 mm |
| Stack | 537 mm | 555 mm | 572 mm | 592 mm | 612 mm |
| Reach | 375 mm | 382 mm | 392 mm | 401 mm | 410 mm |
| Top Tube Length | 523 mm | 540.5 mm | 558 mm | 575.5 mm | 593 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.75 ° | 73.5 ° | 73.25 ° |
| Seat Tube Length | 505 mm | 530 mm | 555 mm | 580 mm | 605 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 72.25 ° | 72.5 ° | 72.75 ° |
| Head Tube Length | 115 mm | 130 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1008 mm | 1011 mm | 1020 mm | 1032 mm | 1045 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 765 mm | 788 mm | 811 mm | 833 mm | 851 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Threshold C Rival 1 completes the Norco Threshold model. There are 58 bikes that carry this model name. Take a sneak peek at all Norco Threshold bikes models from 2017, by clicking here.
Model range prices
Norco Threshold A Tiagra 2017 is the cheapest bike model and costs 1199$. Norco Threshold SL Force 1 2017 is the most expensive one and costs 3799$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Cyclocross bikes average price
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, you could also get a good Cyclocross bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2017 and its price was 2799$. Doing a quick comparison, we notice that Threshold C Rival 1 price is 39.12% higher than the average cost of a Cyclocross bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on Threshold C Rival 1 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Threshold C Rival 1 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
