Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Fork DVO Diamond
-
Groupset GX, NX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Torrent, Aluminum, Boost 12x148mm TA Dropouts
Suspension Fork
DVO Diamond, 140mm Travel, Boost 15x110mm TA
Drivetrain
Rear Derailleur
SRAM GX, 11 Speed
Front Derailleur
-
Shift Levers
Rear: SRAM NX, 11 Speed, Front: -
Cassette
SRAM GX XG-1150, 10-42T, 11 Speed
Crank
Race Face Aeffect SL, 170mm (S/M) | 175mm (L/XL), 30T
Bottom Bracket
Race Face External, Threaded BSA 73mm
Chain
SRAM NX PC-1110, 11 Speed
Pedals
VP Nylon Flat Pedals, 9/16"
Wheels
Front Hub
Novatec 110mm x 15mm
Rear Hub
Novatec D162SB, Boost 12x148mm
Rims
Spank Oozy Trail 395+, 32 Hole, 35mm Internal Width
Tires
Maxxis Minion DHF, 27.5x2.8”, EXO/TR, Folding
Brakes
Brakes
SRAM Level T, 2 Piston Hydraulic Disc, Avid G2 180mm Rotor
Brake Levers
SRAM Level T
Cockpit
Stem
TranzX 6061 Alloy 45mm/35mm
Handlebar
TranzX 6061 DB Alloy 800mm
Grips
Ergon GA30, Lock-On
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco XC Saddle
Seatpost
TranzX YSP07L Stealth Dropper, 150mm Travel, 31.6mm, 1x Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.45 mm | 1.4 mm | 1.35 mm |
| Bottom Bracket Height | 326 mm | 326 mm | 326 mm | 326 mm |
| Front Center | 703 mm | 729 mm | 756 mm | 782 mm |
| Rake | 52 mm | 51 mm | 51 mm | 51 mm |
| Trail | 98 mm | 99 mm | 99 mm | 99 mm |
| Stack | 608 mm | 618 mm | 627 mm | 636 mm |
| Reach | 404 mm | 427 mm | 449 mm | 471 mm |
| Top Tube Length | 590 mm | 620 mm | 650 | 680 mm |
| Seat Tube Angle | 72.9 ° | 72.5 ° | 72.1 ° | 71.7 ° |
| Seat Tube Length | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 425 mm | 428 mm | 430 mm | 433 mm |
| Wheelbase | 1126 mm | 1155 mm | 1183 mm | 1212 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 773 mm | 763 mm | 782 mm | 800 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Torrent HT 1 completes the Norco Torrent model. Norco released 44 bikes variations of this model so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
The most economical model, the Norco Torrent HT 2 2018 has a starting price of 1699$. Norco Torrent 1 FS 2018 on the other hand is the most expensive at 3899$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2599$. In conclusion, this bike price is 6.27% smaller than the price of the average Trail bike.
Torrent HT 1 components
Fork
This bike has the DVO Diamond fork installed. The fork’s travel is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When leaving the production line, the Torrent HT 1 model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Torrent HT 1 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Norco Torrent HT 1 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the Torrent HT 1. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
