Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Acera, Altus -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
VFR Double Butted X6 Alloy w/ Flat Mount Disc
Suspension Fork
Full Carbon w/Flat Mount Disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Acera RD-T3000 - Black
Front Derailleur
Shimano Altus FD-M370
Shift Levers
N/A
Cassette
Shimano CS-HG200 11-32T 9spd
Crank
Shimano Acera FC-T3010 48/36/26T - Black
Bottom Bracket
Cartridge Bearing BB
Chain
KMC X9
Chain Tensioner
N/A
Pedals
Alloy City - Black
Wheels
Front Hub
Alloy Disc w/Labyrinth Seal - Black
Rear Hub
Alloy Disc w/Labyrinth Seal - Black
Rims
Double Wall Alloy Disc 32h - Black
Tires
Schwalbe Spicer 30c w/KevlarGuard
Brakes
Brakes
Tektro HD-R310 Flat Mount Hydraulic Disc
Brake Levers
Tektro HD-R310 Flat Mount Hydraulic Disc
Disk Rotors
N/A
Cockpit
Stem
Norco - Black Stealth
Handlebar
Norco 25mm Riser - Black Stealth
Grips
Dual Density Ergonomic - Black
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco Sport - Black
Seatpost
Norco Alloy 27.2mm - Black Stealth
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14.5" | 16" | 18" | 20" | 22" | 24" |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.42 mm | 1.45 mm | 1.46 mm | 1.48 mm | 1.5 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 614 mm | 625 mm | 635 mm | 650 | 660 mm | 675 mm |
| Rake | 49 mm | 50 mm | 50 mm | 49 mm | 49 mm | 49 mm |
| Trail | 72 mm | 67 mm | 64 mm | 65 mm | 62 mm | 62 mm |
| Stack | 543 mm | 564 mm | 585 mm | 604 mm | 625 mm | 644 mm |
| Reach | 387 mm | 396 mm | 404 mm | 414 mm | 421 mm | 430 mm |
| Top Tube Length | 539 mm | 559 mm | 579 mm | 599 mm | 619 mm | 634 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 365 mm | 412 mm | 459 mm | 510 mm | 562 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm | 200 mm | 220 mm | 240 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1039 mm | 1051 mm | 1061 mm | 1076 mm | 1085 mm | 1100 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 710 mm | 737 mm | 771 mm | 800 mm | 834 mm | 859 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
VFR 3 belongs to the Norco Vfr model. There are 115 bikes that carry this model name. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Norco VFR 24 2017 is the most economical model, with a starting price of 369$. Norco VFR 1 2017 on the other hand costs 1249$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Hybrid bikes average price
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2017 and its price was 799$. Comparing the average cost of a Hybrid bike to this one, you will see that VFR 3 price is 42.17% more expensive.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on VFR 3 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The VFR 3 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
