Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Acera, Altus -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
VFR Performance Hybrid Double Butted Alloy
Suspension Fork
Aerodynamic Chromoly
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Acera RD-M390 - Black
Front Derailleur
Shimano Altus FD-M370
Shift Levers
Shift housing - White
Cassette
Shimano CS-HG20 11-32T 9speed
Crank
Shimano Acera FC-M371 48/36/26T - Black
Bottom Bracket
FSA BB-7420ST Cartridge
Chain
SRAM CN-PC951 9speed
Chain Tensioner
N/A
Pedals
Resin City - Black
Wheels
Front Hub
Formula Alloy 32h - Black
Rear Hub
Formula Alloy 32h - Black
Rims
Double wall alloy 700c x 32hole - Black
Tires
Innova City Hybrid 700 x 32c
Brakes
Brakes
Tektro 837AL V-Brakes - Black
Brake Levers
Shimano Altus ST-M370 2 finger
Disk Rotors
N/A
Cockpit
Stem
Norco 17degree - Black w/Sky Blue
Handlebar
Norco 25mm Riser - Black w/Sky Blue
Grips
Ergonomic Dual Density - White/Sky Blue
Headset
FSA No.11N Semi-cartridge w/20mm spacer
Seat
Saddle
Norco Forma City Comfort - White
Seatpost
Norco Alloy 27.2mm - Black w/Sky Blue
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13" | 14.5" | 16" | 18" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.41 mm | 1.43 mm | 1.46 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 598 mm | 610 mm | 621 mm | 632 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 79 mm | 76 mm | 73 mm | 69 mm |
| Stack | 525 mm | 546 mm | 566 mm | 587 mm |
| Reach | 377 mm | 386 mm | 395 mm | 403 mm |
| Top Tube Length | 518 mm | 538 mm | 558 mm | 578 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 330 mm | 365 mm | 412 mm | 459 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1023 mm | 1035 mm | 1046 mm | 1056 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 703 mm | 724 mm | 751 mm | 781 mm |
| Wheels | 700 | 700 | 700 | 700 |
About this model
VFR 3 Forma completes the Norco Vfr model. Norco released 115 bikes variations of this model so far. Take a sneak peek at all Norco Vfr bikes models from 2014, by clicking here.
Model range prices
Norco VFR 4 Forma 2014 is the cheapest bike model and costs 449$. Norco VFR 1 2014 is the most expensive one and costs 985$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Hybrid bikes
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Norco released this model in 2014, its price was 540$. Comparing the average cost of a Hybrid bike to this one, you will see that VFR 3 Forma price is 4.07% lower.
Overview of components
Fork material
The fork is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
As for the wheels, Norco VFR 3 Forma 2014, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The VFR 3 Forma comes with Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
