Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Altus -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
VFR Double Butted X6 Alloy Disc
Suspension Fork
Aerodynamic Chromoly Disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus RD-M310 8 speed - Black
Front Derailleur
Shimano Altus FD-M191
Shift Levers
Shift housing - Black
Cassette
Shimano CS-HG200 12-32T 8speed
Crank
Shimano Altus FC-M131C 48/38/28T
Bottom Bracket
Cartridge
Chain
KMC Z-72
Chain Tensioner
N/A
Pedals
Resin City - Black
Wheels
Front Hub
Alloy Sealed Disc Hub
Rear Hub
Alloy Sealed Disc Hub
Rims
Double Wall Alloy Disc 32h - Black
Tires
N/A
Brakes
Brakes
Tektro Mechanical Disc w/160mm rotor
Brake Levers
Shimano Easy-Fire w/2-finger lever
Disk Rotors
N/A
Cockpit
Stem
Alloy 15degree - Black
Handlebar
Steel 40mm Riser - Black
Grips
Dual Density Ergonomic - Black/Grey
Headset
FSA No.10 w/20mm spacer
Seat
Saddle
Norco City - Black
Seatpost
Alloy 27.2mm - Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14.5" | 16" | 18" | 20" | 22" | 24" |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.48 mm | 1.51 mm | 1.52 mm | 1.54 mm | 1.56 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 611 mm | 622 mm | 632 mm | 647 mm | 656 mm | 671 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 46 mm |
| Trail | 76 mm | 73 mm | 69 mm | 69 mm | 66 mm | 65 mm |
| Stack | 560 mm | 581 mm | 603 mm | 621 mm | 642 mm | 661 mm |
| Reach | 383 mm | 392 mm | 400 mm | 409 mm | 416 mm | 425 mm |
| Top Tube Length | 539 mm | 559 mm | 579 mm | 599 mm | 619 mm | 634 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 365 mm | 412 mm | 459 mm | 510 mm | 562 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm | 200 mm | 220 mm | 240 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1037 mm | 1048 mm | 1058 mm | 1073 mm | 1081 mm | 1097 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 722 mm | 748 mm | 780 mm | 809 mm | 843 mm | 875 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
VFR 5 belongs to the Norco Vfr model. There are 115 bikes that carry this model name. Check out the entire range from 2016 of this model, by clicking this link.
Model range prices
The most economical model, the Norco VFR 6 Step-Thru 2016 has a starting price of 445$. Norco VFR 1 2016 on the other hand is the most expensive at 1175$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Hybrid bikes
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 539$. In conclusion, this bike price is 4.27% smaller than the price of the average Hybrid bike.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
When it comes to wheels, the VFR 5 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco VFR 5 has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
