Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Altus, Tourney -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
VFR Double Butted X6 Alloy w/ Flat Mount Disc
Suspension Fork
Aerodynamic Chromoly Disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus RD-M310 - Black
Front Derailleur
Shimano Tourney FD-TY710
Shift Levers
N/A
Cassette
Shimano CS-HG200 12-32T 8spd
Crank
Shimano FC-TY501 48/38/28T
Bottom Bracket
Cartridge Bearing BB
Chain
KMC Z-72
Chain Tensioner
N/A
Pedals
Resin City - Black
Wheels
Front Hub
Alloy Sealed Disc Hub
Rear Hub
Alloy Sealed Disc Hub
Rims
Double Wall Alloy Disc 32h - Black
Tires
Kenda Tendril City 700 x 32c
Brakes
Brakes
Tektro Mechanical Disc w/160mm rotor
Brake Levers
Shimano Easy-Fire w/2-finger lever
Disk Rotors
N/A
Cockpit
Stem
Alloy 15degree - Black
Handlebar
Steel 40mm Riser - Black
Grips
Dual Density Ergonomic - Black
Headset
FSA No.10P w/25mm spacer
Seat
Saddle
Norco City - Black
Seatpost
Alloy 27.2mm - Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14.5" | 16" | 18" | 20" | 22" | 24" |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.48 mm | 1.51 mm | 1.52 mm | 1.54 mm | 1.56 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 611 mm | 622 mm | 632 mm | 647 mm | 656 mm | 671 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 46 mm |
| Trail | 76 mm | 73 mm | 69 mm | 69 mm | 66 mm | 65 mm |
| Stack | 560 mm | 581 mm | 603 mm | 621 mm | 642 mm | 661 mm |
| Reach | 383 mm | 392 mm | 400 mm | 409 mm | 416 mm | 425 mm |
| Top Tube Length | 539 mm | 559 mm | 579 mm | 599 mm | 619 mm | 634 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 365 mm | 412 mm | 459 mm | 510 mm | 562 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm | 200 mm | 220 mm | 240 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1037 mm | 1048 mm | 1058 mm | 1073 mm | 1081 mm | 1097 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 722 mm | 748 mm | 780 mm | 809 mm | 843 mm | 875 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
VFR 5 completes the Norco Vfr model. 115 bikes variations carry this model name so far. Take a sneak peek at all Norco Vfr bikes models from 2017, by clicking here.
Model range prices
Norco VFR 24 2017 is the most economical model, with a starting price of 369$. Norco VFR 1 2017 on the other hand costs 1249$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Hybrid bikes average price
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2017 for 539$. Doing a quick comparison, we notice that VFR 5 price is 4.27% smaller than the average cost of a Hybrid bike.
Overview of components
Fork material
VFR 5 has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
When it comes to wheels, the VFR 5 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco VFR 5 has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
