Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour NRX D
-
Groupset X7, Alivio -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
XFR Double Butted 7005 w/Chainstay Disc
Suspension Fork
SR Suntour NRX-D 75mm w/remote lock-out
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X7 - Storm Grey
Front Derailleur
Shimano Alivo FD-M430 - Silver
Shift Levers
Shift housing - Black
Cassette
SRAM PG-950 11-32T 9 speed
Crank
Truvativ Firex 3.1 48/36/26 - Black
Bottom Bracket
Truvativ GXP
Chain
SRAM CN-PC951 9speed
Chain Tensioner
N/A
Pedals
Alloy pedal - Black
Wheels
Front Hub
SRAM 406 Disc Hubs - 32h - Black
Rear Hub
SRAM 406 Disc Hubs - 32h - Black
Rims
WTB SX17 700c - Black w/Blue
Tires
Schwalbe Smart Sam 700x40c
Brakes
Brakes
Avid Elixir 3 w/160mm rotors - Smoke Pewter
Brake Levers
Avid Elixir 3 hydraulic disc levers
Disk Rotors
N/A
Cockpit
Stem
Norco - Black w/Blue
Handlebar
Norco 25mm Riser - Black w/Blue
Grips
X-Over Dual Density - Black/Blue
Headset
FSA ZS-4D ACB Cartridge w/13mm spacer
Seat
Saddle
Norco Urban - Black
Seatpost
Norco Alloy 31.6mm - Black W/Blue
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14.5" | 16" | 18" | 20" | 22" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.63 mm | 1.62 mm | 1.6 mm | 1.57 mm |
| Bottom Bracket Height | 299 mm | 299 mm | 299 mm | 299 mm | 299 mm |
| Front Center | 619 mm | 628 mm | 637 mm | 651 mm | 665 mm |
| Rake | 38 mm | 38 mm | 37 mm | 37 mm | 38 mm |
| Trail | 87 mm | 83 mm | 81 mm | 81 mm | 77 mm |
| Stack | 615 mm | 626 mm | 638 mm | 647 mm | 659 mm |
| Reach | 372 mm | 383 mm | 394 mm | 405 mm | 421 mm |
| Top Tube Length | 549 mm | 569 mm | 589 mm | 609 mm | 629 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 365 mm | 412 mm | 459 mm | 510 mm | 562 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1061 mm | 1070 mm | 1079 mm | 1093 mm | 1108 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 732 mm | 779 mm | 800 mm | 824 mm | 853 mm |
| Front Travel | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
XFR 1 is a Norco Xfr model. 76 bikes variations carry this model name so far. You can get a glimpse at all models from 2014, by clicking on this link.
Model range prices
Norco XFR 3 Forma 2014 is the cheapest bike model and costs 675$. Norco XFR 1 2014 is the most expensive one and costs 1099$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Hybrid bikes
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2014 and its price was 1099$. In conclusion, this bike price is 95.55% more expensive than the price of the average Hybrid bike.
Overview of components
Fork
The fork installed on this bike is the SunTour NRX D model. The travel on this model is 75mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When it comes to wheels, the XFR 1 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
