Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Double Butted X6 Aluminum, Smooth Welds
Suspension Fork
SR Suntour NVX, 75mm, Remote Lock-out
Drivetrain
Rear Derailleur
Shimano Acera RD-M3000
Front Derailleur
Shimano Acera FD-T3000
Shift Levers
Rear: Shimano Altus SL-M2010, 9 speed, Front: Shimano Altus SL-M2010, 2 speed
Cassette
Shimano CS-HG200 11-36T
Crank
Shimano Altus FC-MT210-2, 46/30T
Bottom Bracket
Shimano HollowTech II, Threaded
Chain
KMC X9
Pedals
City
Wheels
Front Hub
Weather Sealed Disc
Rear Hub
Weather Sealed Disc
Rims
WTB SX19
Tires
Impac Smartpac Reflective 700x47c
Brakes
Brakes
Tektro HD-M275 Hydraulic Disc
Brake Levers
Tektro HD-M275 Hydraulic
Cockpit
Stem
Aluminum
Handlebar
Norco Aluminum, 25mm Rise
Grips
Norco
Headset
Zero-Stack Internal Semi-Cartridge Bearing
Seat
Saddle
Norco MTB Sport
Seatpost
Aluminum
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.6 mm | 1.56 mm | 1.52 mm | 1.48 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 291 mm | 291 mm | 291 mm |
| Front Center | 627 mm | 642 mm | 658 mm | 678 mm | 699 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 81 mm | 78 mm | 74 mm | 74 mm | 74 mm |
| Stack | 625 mm | 635 mm | 646 mm | 655 mm | 665 mm |
| Reach | 381 mm | 398 mm | 415 mm | 432 mm | 449 mm |
| Top Tube Length | 557 mm | 582 mm | 607 mm | 632 mm | 657 mm |
| Seat Tube Angle | 74.1 ° | 73.7 ° | 73.3 ° | 72.9 ° | 72.5 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 107.5 mm | 115 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 462 mm | 462 mm | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1080 mm | 1095 mm | 1113 mm | 1133 mm | 1154 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 639 mm | 679 mm | 721 mm | 757 mm | 793 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
XFR 1 belongs to the Norco Xfr model. There are 76 bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Norco XFR 4 2020 is the most affordable bike of this model and has a price of 549$. On the other hand, Norco XFR 1 2020, is the most expensive and costs 799$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Hybrid bikes
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2020 for 799$. Doing a quick comparison, we notice that XFR 1 price is 42.17% higher than the average cost of a Hybrid bike.
XFR 1 components
Fork
The SunTour is included from the factory. It has a travel distance of 75mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When leaving the production line, the XFR 1 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The XFR 1 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
XFR 1 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
