Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
XFR Double Butted X6 w/CS Disc and Flip
Suspension Fork
SR Suntour NVX 75mm w/Hydraulic Lock-Out
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Acera RD-M3000 Shadow
Front Derailleur
Shimano Altus FD-M191
Shift Levers
Shift housing - Matte Black
Cassette
Shimano CS-HG200 12-32T 8speed
Crank
Shimano Acera FC-M361 48/38/28T - Black
Bottom Bracket
Cartridge BB
Chain
KMC Z72 8spd Chain Grey/Brown
Chain Tensioner
N/A
Pedals
Alloy pedal - Black
Wheels
Front Hub
Shimano CenterLock - Black
Rear Hub
Shimano CenterLock - Black
Rims
Double wall alloy 700c x 32hole - Black
Tires
N/A
Brakes
Brakes
Shimano BR-M395 Hydraulic w/160mm - Black
Brake Levers
Shimano BL-M395 - Black
Disk Rotors
N/A
Cockpit
Stem
Norco - Black
Handlebar
Norco 25mm Riser - Black
Grips
Dual Density Ergonomic - Black/Grey
Headset
FSA No.11N Semi-cartridge w/20mm spacer
Seat
Saddle
Norco MTB Sport - Black
Seatpost
Norco Alloy 27.2mm - Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.6 mm | 1.56 mm | 1.52 mm | 1.48 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 291 mm | 291 mm | 291 mm |
| Front Center | 626 mm | 642 mm | 658 mm | 679 mm | 699 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 47 mm |
| Trail | 78 mm | 75 mm | 72 mm | 72 mm | 70 mm |
| Stack | 625 mm | 635 mm | 646 mm | 655 mm | 665 mm |
| Reach | 381 mm | 398 mm | 415 mm | 432 mm | 449 mm |
| Top Tube Length | 557 mm | 582 mm | 607 mm | 632 mm | 657 mm |
| Seat Tube Angle | 74.1 ° | 73.7 ° | 73.3 ° | 72.9 ° | 72.5 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 107.5 mm | 115 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 462 mm | 462 mm | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1080 mm | 1095 mm | 1113 mm | 1133 mm | 1154 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 745 mm | 769 mm | 804 mm | 827 mm | 849 mm |
| Front Travel | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
XFR 3 is a Norco Xfr model. There are 76 bikes that carry this model name. You can get a glimpse at all models from 2016, by clicking on this link.
Model range prices
Norco XFR 4 Forma 2016 is the most affordable bike of this model and has a price of 555$. On the other hand, Norco XFR 1 2016, is the most expensive and costs 1095$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Hybrid bikes
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2016 for 695$. In conclusion, this bike price is 23.67% higher than the price of the average Hybrid bike.
XFR 3 components
Fork
This bike has the SunTour fork installed. The fork’s travel is 75mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Norco XFR 3 2016, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
XFR 3 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
