Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour
-
Groupset X4, Altus -
Suspension Hardtail -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
XFR Double Butted 7005 w/Chainstay Disc
Suspension Fork
SR Suntour NVX 75mm w/lock-out
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X4 black
Front Derailleur
Shimano Altus FD-M191
Shift Levers
Shift housing - White
Cassette
SRAM PG-820 11-32
Crank
SRAM S650 3.0 48/36/26 - Black
Bottom Bracket
SRAM Cartridge BB
Chain
KMC Z-72
Chain Tensioner
N/A
Pedals
Alloy pedal - Black
Wheels
Front Hub
Shimano HB-RM35 CenterLock Disc - Black
Rear Hub
Shimano FH-RM35 CenterLock Disc - Black
Rims
Double wall alloy 700c x 32hole - Black
Tires
Norco X-Over 700x42c
Brakes
Brakes
Shimano BR-M446 w/160mm rotors - Black
Brake Levers
Shimano BR-M446 - Black
Disk Rotors
N/A
Cockpit
Stem
Norco - Black w/Pink
Handlebar
Norco 25mm Riser - Black w/Pink
Grips
Norco Gradient Dual Density - Black/Pink
Headset
FSA No.11N Semi-cartridge w/20mm spacer
Seat
Saddle
Norco Forma Urban - White
Seatpost
Norco - Black w/Pink
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | - | - | - | - |
|---|---|---|---|---|
| Stack Reach Ratio | 1.67 mm | 1.65 mm | 1.64 mm | 1.62 mm |
| Bottom Bracket Height | 299 mm | 299 mm | 299 mm | 299 mm |
| Front Center | 609 mm | 619 mm | 628 mm | 637 mm |
| Rake | 38 mm | 38 mm | 38 mm | 37 mm |
| Trail | 90 mm | 87 mm | 83 mm | 81 mm |
| Stack | 602 mm | 614 mm | 625 mm | 637 mm |
| Reach | 360 mm | 371 mm | 382 mm | 393 mm |
| Top Tube Length | 528 mm | 548 mm | 568 mm | 588 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 330 mm | 365 mm | 412 mm | 459 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70.5 ° | 71 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1050 mm | 1060 mm | 1069 mm | 1078 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 |
About this model
XFR 3 Forma is a Norco Xfr model. There are 76 bikes that carry this model name. You can get a glimpse at all models from 2013, by clicking on this link.
Model range prices
Norco XFR 3 Forma 2013 is the most affordable bike of this model and has a price of 705$. On the other hand, Norco XFR 1 2013, is the most expensive and costs 1165$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Hybrid bikes average price
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Norco XFR 3 Forma price was 705$. If we compare this with the average Hybrid bike cost we notice that the price is 25.44% more expensive.
XFR 3 Forma components
Fork
The SunTour is included from the factory. It has a travel distance of 75mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the XFR 3 Forma bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco XFR 3 Forma is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
