Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
XFR Double Butted 7005 w/Chainstay Disc
Suspension Fork
SR Suntour NVX 75mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus RD-M370 - Black
Front Derailleur
Shimano Altus FD-M191
Shift Levers
Shift housing - Dark Grey
Cassette
Shimano CS-HG200 12-32T 8speed
Crank
Shimano Altus FC-M171 48/38/28T - Black
Bottom Bracket
Cartridge BB
Chain
8spd Chain Grey/Brown
Chain Tensioner
N/A
Pedals
Resin City - Black
Wheels
Front Hub
SRAM 306 Disc Hubs - 32h - Black
Rear Hub
SRAM 306 Disc Hubs - 32h - Black
Rims
Double wall alloy 700c x 32hole - Black
Tires
Norco X-Over 700x42c
Brakes
Brakes
Tektro Aires mech disc w/160mm rotor
Brake Levers
Shimano ST-EF51 EZ Fire - Black
Disk Rotors
N/A
Cockpit
Stem
Alloy - Black
Handlebar
Alloy 25mm Riser - Black
Grips
Dual Density Ergonomic - Black/Grey
Headset
FSA No.11N Semi-cartridge w/20mm spacer
Seat
Saddle
Norco Urban - Black
Seatpost
Alloy 31.6mm - Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14.5" | 16" | 18" | 20" | 22" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.63 mm | 1.62 mm | 1.6 mm | 1.57 mm |
| Bottom Bracket Height | 299 mm | 299 mm | 299 mm | 299 mm | 299 mm |
| Front Center | 619 mm | 628 mm | 637 mm | 651 mm | 665 mm |
| Rake | 38 mm | 38 mm | 37 mm | 37 mm | 38 mm |
| Trail | 87 mm | 83 mm | 81 mm | 81 mm | 77 mm |
| Stack | 615 mm | 626 mm | 638 mm | 647 mm | 659 mm |
| Reach | 372 mm | 383 mm | 394 mm | 405 mm | 421 mm |
| Top Tube Length | 549 mm | 569 mm | 589 mm | 609 mm | 629 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 365 mm | 412 mm | 459 mm | 510 mm | 562 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 454 mm | 454 mm | 454 mm | 454 mm | 454 mm |
| Wheelbase | 1066 mm | 1075 mm | 1084 mm | 1098 mm | 1113 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 732 mm | 779 mm | 800 mm | 824 mm | 853 mm |
| Front Travel | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
XFR 4 is a Norco Xfr model. Norco released 76 bikes variations of this model so far. You can get a glimpse at all models from 2015, by clicking on this link.
Model range prices
Norco XFR 4 2015 is the most affordable bike of this model and has a price of 535$. On the other hand, Norco XFR 1 2015, is the most expensive and costs 1035$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2015 for 535$. If we compare this with the average Hybrid bike cost we notice that the price is 5.05% lower.
XFR 4 components
Fork
This bike has the SunTour fork installed. The fork’s travel is 75mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the XFR 4 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The XFR 4 has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
