Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco XFR, Aluminum, 9x135mm QR Dropouts
Suspension Fork
SR Suntour NVX, 75mm Travel, 9x100mm QR
Drivetrain
Rear Derailleur
Shimano RD-TY500, SGS, 7 Speed
Front Derailleur
Shimano Tourney FD-TY710, 3 Speed
Shift Levers
Rear: Shimano ST-EF500, Easy-Fire, 7 Speed, Front: Shimano ST-EF500, Easy-Fire, 3 Speed
Cassette
Shimano Tourney CS-HG200, 12-32T, 7 Speed
Crank
Shimano FC-TY301, 170mm (XS/S) | 175mm (M/L/XL), 48/38/28T
Bottom Bracket
Cartridge BB, Threaded BSA 73mm
Chain
KMC Z50, 7 Speed
Pedals
City - Black
Wheels
Front Hub
Alloy Sealed Disc Hub
Rear Hub
Alloy Sealed Disc Hub, 32 Hole, 10x135mm QR
Rims
WTB SX19, 32 Hole, 19mm Internal Width
Tires
Impac Smartpac, 700x47c
Brakes
Brakes
Tektro MD-M280, Mechanical Disc, 160mm Rotor
Brake Levers
Shimano Easy-Fire, 2 Finger Levers
Cockpit
Stem
Norco SL Alloy - Black
Handlebar
Norco Alloy 25mm Riser - Black
Grips
Norco, Black
Headset
Zero Stack Headset w/15mm spacer
Seat
Saddle
Norco MTB Sport - Black
Seatpost
Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.6 mm | 1.56 mm | 1.52 mm | 1.48 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 291 mm | 291 mm | 291 mm |
| Front Center | 626 mm | 642 mm | 658 mm | 679 mm | 699 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 47 mm |
| Trail | 78 mm | 75 mm | 72 mm | 72 mm | 70 mm |
| Stack | 625 mm | 635 mm | 646 mm | 655 mm | 665 mm |
| Reach | 381 mm | 398 mm | 415 mm | 432 mm | 449 mm |
| Top Tube Length | 557 mm | 582 mm | 607 mm | 632 mm | 657 mm |
| Seat Tube Angle | 74.1 ° | 73.7 ° | 73.3 ° | 72.9 ° | 72.5 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 107.5 mm | 115 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 462 mm | 462 mm | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1080 mm | 1095 mm | 1113 mm | 1133 mm | 1154 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 745 mm | 769 mm | 804 mm | 827 mm | 849 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
XFR 4 completes the Norco Xfr model. There are 76 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Norco XFR 4 Step-Thru 2019 is the most affordable bike of this model and has a price of 549$. On the other hand, Norco XFR 1 2019, is the most expensive and costs 899$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 549$. If we compare this with the average Hybrid bike cost we notice that the price is 2.37% lower.
Overview of components
Fork
This bike has the SunTour fork installed. The fork’s travel is 75mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The XFR 4 2019 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The XFR 4 comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Norco XFR 4 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
