Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tourney, Altus -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
7005 alloy w/comfort stays
Suspension Fork
Hi-Tensile steel hybrid fork
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney RD-TX55
Front Derailleur
Shimano Tourney FD-TX51
Shift Levers
N/A
Cassette
Shimano MF-TZ31 Megarange 14-34T 7speed
Crank
Shimano Altus FC-M131C 48/38/28T
Bottom Bracket
Cartridge BB
Chain
KMC Z-50
Chain Tensioner
N/A
Pedals
Wellgo Resin Comfort Pedal w/ Kraton
Wheels
Front Hub
KT Alloy hub 32h - Silver
Rear Hub
KT Alloy hub w/Cassette 32h - Silver
Rims
Double wall alloy w/CNC side wall 32h - Silver
Tires
CST C-1096 700x35C
Brakes
Brakes
Tektro 837AL V-Brakes
Brake Levers
Shimano Altus Easy-Fire 51 w/4-finger levers
Disk Rotors
N/A
Cockpit
Stem
Forged alloy adjustable stem
Handlebar
Steel comfort high riser bar
Grips
Ergonomic w/Norco logo bar plug
Headset
Alloy threaded sealed bearing - Black
Seat
Saddle
Selle Royal Loire Saddle
Seatpost
Alloy suspension seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.56 mm | 1.53 mm |
| Bottom Bracket Height | 287 mm | 287 mm | 287 mm |
| Front Center | 628 mm | 643 mm | 658 mm |
| Rake | 45 mm | 49 mm | 42 mm |
| Trail | 82 mm | 78 mm | 86 mm |
| Stack | 606 mm | 615 mm | 625 mm |
| Reach | 382 mm | 395 mm | 409 mm |
| Top Tube Length | 601 mm | 616 mm | 631 mm |
| Seat Tube Angle | 70 ° | 70 ° | 70 ° |
| Seat Tube Length | 355 mm | 415 mm | 475 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 170 mm | 180 mm | 190 mm |
| Chainstay Length | 476 mm | 476 mm | 476 mm |
| Wheelbase | 1096 mm | 1116 mm | 1126 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 597 mm | 570 mm | 545 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Yorkville Step-Thru completes the Norco Yorkville model. Norco released 32 bikes variations of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Norco Yorkville Step-Thru 2017 is the cheapest bike model and costs 369$. Norco Yorkville 2017 is the most expensive one and costs 369$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Norco Yorkville Step-Thru price was 369$. If we compare this with the average Hybrid bike cost we notice that the price is 52.3% smaller.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
The Yorkville Step-Thru 2017 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Yorkville Step-Thru is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
Sizes
Yorkville Step-Thru comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
