Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Factory Float 34
-
Groupset X01 Eagle, GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX Factory 34 Float FIT4, 3 position adjustment with open mode adjustment, 15x110mm Boost, 1.5" tapered steerer tube, 44 offset
Rear Shock
FOX Factory Float DPS, 3 position adjustment, EVOL LV, Trunnion mount, 185x55mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle, type 3, 12-speed
Front Derailleur
None
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM XG-1275, 10-50 tooth, 12-speed
Crank
Truvativ Descendant Carbon DUB, 170mm
Bottom Bracket
SRAM DUB, BB92
Chain
SRAM, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Front: NS Rotary 15, Boost 15x110 disc, sealed bearings, Rear: NS Rotary Cassette, 148x12mm Boost, sealed bearings
Rear Hub
Front: NS Rotary 15, Boost 15x110 disc, sealed bearings, Rear: NS Rotary Cassette, 148x12mm Boost, sealed bearings
Rims
NS Enigma Roll 29", 32 hole, tubeless ready
Spokes
14mm nipples
Tires
Schwalbe Nobby Nic 29x2.35", folding, TLE
Brakes
Brakes
SRAM Guide RS, 180mm rotors
Brake Levers
SRAM Guide RS
Cockpit
Stem
NS Quantum Lite 35, 45mm
Handlebar
NS Licence Carbon 35, 780mm
Grips
NS Hold Fast
Headset
NS custom tapered 1.125"-1.5", IS42/IS52 reach adjustable offset cups (+/-10mm), sealed bearing
Seat
Saddle
Octane One Crit, Ti-Alloy rails
Seatpost
FOX Transfer Performance Elite, 125mm on M, 150mm on L
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.31 mm |
| Bottom Bracket Height | 329 mm | 329 mm |
| Stack | 630 mm | 639 mm |
| Reach | 458 mm | 488 mm |
| Top Tube Length | 608 mm | 641 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° |
| Seat Tube Length | 432 mm | 453 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° |
| Head Tube Length | 120 mm | 130 mm |
| Chainstay Length | 438 mm | 438 mm |
| Wheelbase | 1220 mm | 1254 mm |
| Bottom Bracket Drop | 45 mm | 45 mm |
| Standover Height | 755 mm | 786 mm |
| Wheels | 29" | 29" |
Model Overview
Define 130 1 is a Ns Define model. NS released 38 bikes variations of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Trail bikes
If we make a quick analysis of the average weight of a Trail bike, we get 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 13.2 kg (29.1 lbs), the Define 130 1 model is slightly heavier than average. To sum up, it’s 1.69% heavier than the average weight of Trail bikes.
Overview of components
Fork
This bike has the Fox Factory Float 34 fork installed. The fork’s travel is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is FOX Factory Float DPS, with a travel distance of 130mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When it comes to wheels, the Define 130 1 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Define 130 1 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Dropper post
A dropper post is included with the Define 130 1. Therefore, climbing or descending will be a breeze.
