Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Factory Float 34
-
Groupset X01 Eagle, GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 34 Factory, FIT4 damper, 3-position adjust, Open Mode adjust, 44mm offset
Rear Shock
FOX FLOAT DPS Factory, EVOL LV, 3-position adjust, trunnion mount, 185mm x 55mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM GX Eagle XG-1275, 12-speed, 10-50 tooth
Crank
Truvativ Descendant Carbon Eagle DUB, 170mm length
Bottom Bracket
SRAM DUB, BB92 PressFit
Chain
SRAM, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
NS Rotary, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rear Hub
NS Rotary, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rims
NS Enigma Roll, 32 hole, tubeless compatible
Spokes
14mm nipples
Tires
Schwalbe Nobby Nic, TL-Easy, folding, 29" x 2.35"
Brakes
Brakes
SRAM G2 RSC, 4-piston, 200mm front rotor, 180mm rear rotor
Brake Levers
SRAM G2 RSC
Cockpit
Stem
NS Quantum Lite, 45mm length, 35mm bar clamp
Handlebar
NS License Carbon, 780mm width, 35mm clamp diameter
Grips
NS Hold Fast
Headset
NS custom tapered, adjustable offset cups, IS42 upper, IS52 lower, sealed bearings
Seat
Saddle
Octane One Crit, Ti alloy rails
Seatpost
FOX Transfer Performance Elite dropper, 150mm or 175mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.31 mm |
| Bottom Bracket Height | 329 mm | 329 mm |
| Stack | 630 mm | 639 mm |
| Reach | 458 mm | 488 mm |
| Top Tube Length | 604 mm | 641 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° |
| Chainstay Length | 438 mm | 438 mm |
| Wheelbase | 1215 mm | 1248 mm |
| Bottom Bracket Drop | 45 mm | 45 mm |
| Standover Height | 755 mm | 786 mm |
| Wheels | 29" | 29" |
Model Overview
Define 130 1 completes the Ns Define model. 38 bikes variations carry this model name so far. You can get a glimpse at all models from 2021, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Trail bikes
If we make a quick analysis of the average weight of a Trail bike, we get 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
NS Define 130 1 it’s weighing 13.2 kg (29.1 lbs). At this weight, is slightly heavier than average. In other words, this model is 1.69% heavier than the average Trail bike.
Define 130 1 components
Fork
NS Define 130 1 2021 bike is equipped with the Fox Factory Float 34 fork, and has 140mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Define 130 1 has a rear shock with a travel of 130mm. The model FOX FLOAT DPS Factory is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The wheels on Define 130 1 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Define 130 1 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Dropper post
The NS model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
