Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX 34 FLOAT Performance, GRIP damper, Sweep Adjust, 44mm offset, 110x15mm Boost thru-axle
Rear Shock
FOX FLOAT DPS Performance, 3-position adjust, EVOL LV, trunnion mount, 185mm x 55mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed, Type 3
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle, 12-speed
Cassette
SRAM PG-1230, 12-speed, 11-50 tooth
Crank
Truvativ Descendant DUB, 170mm length
Bottom Bracket
SRAM DUB PressFit BB92
Chain
SRAM, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
NS Rotary, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
NS Rotary, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear
Rims
Octane One Solar, 32 hole, tubeless ready
Spokes
14mm nipples
Tires
Schwalbe Nobby Nic, 29" x 2.35"
Brakes
Brakes
SRAM Guide R, 4-piston, 200mm front rotor, 180mm rear rotor
Brake Levers
SRAM Guide R
Cockpit
Stem
NS Quantum Lite, 35mm clamp, 45mm length
Handlebar
NS, 35mm bore, 780mm width, 20mm rise
Grips
NS Hold Fast
Headset
NS custom tapered IS42/IS52 reach adjustable offset cups (+/- 10mm), sealed bearing
Seat
Saddle
Octane One Crit, CrMo rails
Seatpost
X-Fusion Manic internal dropper, 125mm or 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.31 mm |
| Bottom Bracket Height | 332 mm | 332 mm |
| Front Center | 780 mm | 813 mm |
| Rake | 46 mm | 45 mm |
| Trail | 120 mm | 121 mm |
| Stack | 630 mm | 639 mm |
| Reach | 458 mm | 488 mm |
| Top Tube Length | 604 mm | 641 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° |
| Chainstay Length | 438 mm | 438 mm |
| Wheelbase | 1215 mm | 1248 mm |
| Bottom Bracket Drop | 42 mm | 42 mm |
| Standover Height | 755 mm | 786 mm |
| Wheels | 29" | 29" |
About this model
Define 130 2 is a Ns Define model. NS launched 38 bikes of this model so far. Take a sneak peek at all Ns Define bikes models from 2020, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Trail bikes average weight
Trail bikes have an average weight of 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Define 130 2 weighs 13.8 kg (30.42 lbs) and is a bit heavier than the average. In short, the average Trail bike weight is 6.32% lower than this one.
Define 130 2 components
Fork
The Fox Performance Float 34 is included from the factory. It has a travel distance of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is FOX FLOAT DPS Performance, with a travel distance of 130mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The wheels on Define 130 2 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
