Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 34 Performance, GRIP damper, Sweep Adjust, 44mm offset
Rear Shock
FOX FLOAT DPS Performance, EVOL LV, 3-position adjust, trunnion mount, 185mm x 55mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM NX Eagle, 12-speed
Cassette
SRAM SX Eagle PG-1210, 12-speed, 11-50 tooth
Crank
Truvativ Descendant 6K Eagle DUB, 170mm length
Bottom Bracket
SRAM DUB, BB92 PressFit
Chain
SRAM, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
NS Rotary, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
NS Rotary, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
Octane One Solar, 32 hole, tubeless compatible
Spokes
14mm nipples
Tires
Maxxis Rekon, Dual Compound, EXO, TR, 29" x 2.4" WT
Brakes
Brakes
SRAM Guide R, 4-piston, 200mm front rotor, 180mm rear rotor
Brake Levers
SRAM Guide R
Cockpit
Stem
NS Quantum Lite, 45mm length, 35mm bar clamp
Handlebar
NS, 780mm width, 20mm rise, 35mm clamp diameter
Grips
NS Hold Fast
Headset
NS custom tapered, adjustable offset cups, IS42 upper, IS52 lower, sealed bearings
Seat
Saddle
Octane One Crit, hollow CrMo rails
Seatpost
X-Fusion Manic dropper, 125mm or 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.31 mm |
| Bottom Bracket Height | 329 mm | 329 mm |
| Stack | 630 mm | 639 mm |
| Reach | 458 mm | 488 mm |
| Top Tube Length | 604 mm | 641 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° |
| Chainstay Length | 438 mm | 438 mm |
| Wheelbase | 1215 mm | 1248 mm |
| Bottom Bracket Drop | 45 mm | 45 mm |
| Standover Height | 755 mm | 786 mm |
| Wheels | 29" | 29" |
About this model
Define 130 2 is part of the Ns Define model. There are 38 bikes that carry this model name. You can easily view all of the Ns Define bikes models from 2021, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail bikes
The average weight for Trail bikes is 12.98 kg (28.62 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 13.9 kg (30.64 lbs), the Define 130 2 model is a bit heavier than average. To sum up, it’s 7.09% heavier than the average weight of Trail bikes.
Overview of components
Fork
The Define 130 2 comes factory-installed with the Fox Performance Float 34 fork. This has a travel range of 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Define 130 2 has a rear shock with a travel of 130mm. The model FOX FLOAT DPS Performance is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, NS Define 130 2 2021, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Dropper post
NS Define 130 2 includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
