Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Performance Float 36
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX FLOAT 36 Performance, GRIP damper, 3-position adjust, open mode adjust, 44mm offset
Rear Shock
FOX FLOAT DPX2 Performance, 3-position adjust, EVOL LV, trunnion mount, 205mm x 65mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed, Type 3
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle, 12-speed
Cassette
SRAM SX Eagle PG-1210, 12-speed, 11-50 tooth
Crank
Truvativ Descendant Alloy DUB, 170mm length
Bottom Bracket
SRAM DUB, 73mm BSA threaded
Chain
SRAM, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
NS Rotary, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
NS Rotary, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
Octane One Solar, 32 hole, tubeless ready
Spokes
14mm nipples
Tires
Front: Maxxis Minion DHF, EXO, TR, 29" x 2.5" WT, Rear: Maxxis Aggressor, EXO, TR, 29" x 2.5" WT
Brakes
Brakes
SRAM Guide RE, 4-piston, 200mm front rotor, 180mm rear rotor
Brake Levers
SRAM Guide RE
Cockpit
Stem
NS Quantum Lite, 35mm clamp, 45mm length
Handlebar
NS, 35mm clamp diameter, 780mm width, 20mm rise
Grips
NS Hold Fast, supersoft
Headset
Integrated tapered, IS42 upper, IS52 lower, sealed bearings
Seat
Saddle
Octane One Crit, hollow CrMo rails
Seatpost
X-Fusion Manic internal dropper, 125mm or 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.39 mm | 1.33 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm |
| Stack | 626 mm | 635 mm | 644 mm |
| Reach | 426 mm | 456 mm | 486 mm |
| Top Tube Length | 582 mm | 615 mm | 648 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 396 mm | 432 mm | 483 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1197 mm | 1232 mm | 1266 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm |
| Standover Height | 742 mm | 738 mm | 435 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Define 150 AL is part of the Ns Define model. NS released 38 bikes variations of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Enduro bikes
Enduro bikes weigh an average of 14.27 kg (31.46 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 14.9 kg (32.85 lbs), NS bike is slightly heavier than average. In short, the average Enduro bike weight is 4.41% lower than this one.
Define 150 AL components
Fork
The Fox Performance Float 36 is included from the factory. It has a travel distance of 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this bike is FOX FLOAT DPX2 Performance, with a travel distance of 150mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When it comes to wheels, the Define 150 AL bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Define 150 AL has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
NS Define 150 AL bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
A dropper post is included with the Define 150 AL. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
