Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 160mm -
Fork RockShox 35 Gold RL
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox 35 Gold RL, 37mm offset
Rear Shock
X-Fusion H3C, 3-position platform, low-speed compression adjust, rebound adjust, trunnion mount, 205mm x 65mm, Spring rates: 350lbs (SM), 400lbs (MD), 450lbs (LG)
Drivetrain
Rear Derailleur
Shimano Deore M6100, 12-speed
Front Derailleur
None
Shift Levers
Shimano Deore M6100, 12-speed
Cassette
SunRace CSMZ800, 12-speed, 11-51 tooth
Crank
Shimano Deore MT5101, 170mm length
Bottom Bracket
Shimano, 73mm English/BSA threaded
Chain
Shimano, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
NS, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
NS, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
Octane One Solar, 32 hole, tubeless compatible
Spokes
14mm nipples
Tires
Schwalbe Big Betty, BikePark, 27.5" x 2.4"
Brakes
Brakes
Shimano MT410, 2-piston, 200mm front rotor, 180mm rear rotor
Brake Levers
Shimano MT410
Cockpit
Stem
NS Tone, 45mm length, 35mm bar clamp
Handlebar
NS, 780mm width, 20mm rise, 35mm clamp diameter
Grips
NS Hold Fast
Headset
Integrated tapered, IS42 upper, IS52 lower, sealed bearings
Seat
Saddle
Octane One Crit, hollow CrMo rails
Seatpost
X-Fusion Manic dropper, Drop: 125mm (SM), 150mm (MD), 170mm (LG)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.29 mm | 1.23 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm |
| Stack | 590 mm | 599 mm | 608 mm |
| Reach | 436 mm | 466 mm | 496 mm |
| Top Tube Length | 579 mm | 612 mm | 645 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 396 mm | 432 mm | 483 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° |
| Chainstay Length | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1194 mm | 1228 mm | 1262 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm |
| Standover Height | 739 mm | 739 mm | 735 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Define 160 AL completes the Ns Define model. 38 bikes variations carry this model name so far. You can easily view all of the Ns Define bikes models from 2021, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro bikes
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Enduro bikes
Enduro bikes weigh an average of 14.27 kg (31.46 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 15.1 kg (33.29 lbs), the Define 160 AL model is a bit heavier than average. In other words, this model is 5.82% heavier than the average Enduro bike.
Define 160 AL components
Fork
The Define 160 AL comes factory-installed with the RockShox 35 Gold RL fork. This has a travel range of 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is X-Fusion H3C, with a travel distance of 160mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Define 160 AL are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. NS Define 160 AL has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
