Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 180mm -
Travel Rear 170mm -
Fork RockShox ZEB
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox ZEB, 44mm offset
Rear Shock
X-Fusion Vector R, trunnion mount, 225mm x 70mm, Spring rates: 350lbs (SM), 400lbs (MD), 450lbs (LG)
Drivetrain
Rear Derailleur
Shimano Deore M6100, 12-speed
Front Derailleur
None
Shift Levers
Shimano Deore M6100, 12-speed
Cassette
SunRace CSMZ800, 12-speed, 11-51 tooth
Crank
Shimano Deore MT5101, 170mm length
Bottom Bracket
Shimano, 73mm English/BSA threaded
Chain
Shimano, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
NS, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
NS, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
Octane One Solar, 32 hole, tubeless compatible
Spokes
14mm nipples
Tires
Schwalbe Big Betty, BikePark, 2.4"
Brakes
Brakes
Shimano MT420, 4-piston, 200mm rotors
Brake Levers
Shimano MT420
Cockpit
Stem
NS Tone, 45mm length, 35mm bar clamp
Handlebar
NS, 800mm width, 20mm rise, 35mm clamp diameter
Grips
NS Hold Fast
Headset
GW, integrated tapered, IS42 upper, IS52 lower, sealed bearings
Seat
Saddle
Octane One Rocket2, hollow CrMo rails
Seatpost
X-Fusion Manic dropper, Drop: 125mm (SM), 150mm (MD), 170mm (LG)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.4 mm | 1.34 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm |
| Stack | 640 mm | 640 mm | 649 mm |
| Reach | 426 mm | 456 mm | 486 mm |
| Top Tube Length | 588 mm | 620 mm | 650 |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 396 mm | 432 mm | 483 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° |
| Chainstay Length | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1214 mm | 1244 mm | 1280 mm |
| Bottom Bracket Drop | 6 mm | 6 mm | 6 mm |
| Standover Height | 761 mm | 753 mm | 748 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Define 170 AL 2 completes the Ns Define model. NS released 38 bikes variations of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro bikes average price
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Enduro bikes
The average weight for Enduro bikes is 14.27 kg (31.46 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 15.8 kg (34.83 lbs), the Define 170 AL 2 model is considerably heavier than average. In other words, this model is 10.72% heavier than the average Enduro bike.
Define 170 AL 2 components
Fork
This bike has the RockShox ZEB fork installed. The fork’s travel is 180mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the X-Fusion Vector R rear shock model, which has a travel of 170mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When it comes to wheels, the Define 170 AL 2 bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Define 170 AL 2 comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
