Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 203mm -
Travel Rear 203mm -
Fork Fox Performance Elite Float 40
-
Groupset GX, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Performance Elite 40 FIT4, LSC, 20x110mm thru-axle, 52mm offset
Rear Shock
FOX Performance Elite DHX2, LSC, LSR, 9.5" x 3.0" (240mm x 76mm), M: 450lb spring, L: 500 lbs spring
Drivetrain
Rear Derailleur
SRAM GX DH X-Horizon, 7-speed
Front Derailleur
N/A (1x-specific)
Shift Levers
SRAM GX DH, 7-speed
Cassette
CS PG 720 DH, 11-25 tooth
Crank
Truvativ Descendant, 165mm length
Bottom Bracket
Truvativ GXP, 83mm threaded
Chain
KMC, 11-speed
Chain Guide
Mozartt Presto Alu with bashguard
Pedals
N/A
Wheels
Front Hub
Front: NS Rotary 20 disc, sealed bearing, Rear: NS Rotary Cassette, 157mm, sealed bearing
Rear Hub
Front: NS Rotary 20 disc, sealed bearing, Rear: NS Rotary Cassette, 157mm, sealed bearing
Rims
NS Enigma Rock, 32 hole
Spokes
14g-2.0mm, 14mm nipples
Tires
Schwalbe Magic Mary, black 60-584 wire bead VSC Downhill, 27.5" x 2.35"
Brakes
Brakes
SRAM Code R, 200mm rotors
Brake Levers
SRAM Code R
Cockpit
Stem
NS Direct Mount, 31.8mm clamp, 40-48mm length (2 positions)
Handlebar
NS Evidence Plus, 800mm width
Grips
NS Hold Fast
Headset
NS custom 1.5" EX56/56, sealed bearings, reach adjustable offset cups (0, +8, -8mm)
Seat
Saddle
Octane One Crit, cromoly rails
Seatpost
Kalloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.361 mm | 1.322 mm |
| Bottom Bracket Height | 353 mm | 353 mm |
| Front Center | 813 mm | 838 mm |
| Rake | 46 mm | 46 mm |
| Trail | 133 mm | 133 mm |
| Stack | 607 mm | 616 mm |
| Reach | 446 mm | 466 mm |
| Top Tube Length | 630 mm | 655 mm |
| Seat Tube Angle | 73 ° | 73 ° |
| Seat Tube Length | 400 mm | 411 mm |
| Head Tube Angle | 62.5 ° | 62.5 ° |
| Head Tube Length | 120 mm | 120 mm |
| Chainstay Length | 442 mm | 454 mm |
| Wheelbase | 1255 mm | 1292 mm |
| Bottom Bracket Drop | 2 mm | 2 mm |
| Standover Height | 692 mm | 691 mm |
| Wheels | 27" | 27" |
About this model
Fuzz 1 is a Ns Fuzz model. 16 bikes variations carry this model name so far. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Downhill bikes
If you want to purchase a solid Downhill bike, it is important to know that the average cost is 3391$. However, you could also get a good Downhill bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Downhill bikes average weight
Downhill bikes have an average weight of 15.89 kg (35.03 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 16.9 kg (37.26 lbs), the Fuzz 1 model is a bit heavier than average. In conclusion, the average Downhill bike weighs 6.36% less than Fuzz 1.
Overview of components
Fork
This bike has the Fox Performance Elite Float 40 fork installed. The fork’s travel is 203mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the FOX Performance Elite DHX2 rear shock model, which has a travel of 203mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When leaving the production line, the Fuzz 1 model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. NS Fuzz 1 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
