Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" / 27.5" -
Travel Front 160mm -
Travel Rear 180mm -
Fork X Fusion
-
Groupset Deore, Suntour SR -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
X-Fusion Trace 29 RC, 15x110mm Boost, 1.5 tapered steerer tube
Rear Shock
X-Fusion 02 Pro RL, 230x65mm
Drivetrain
Rear Derailleur
Shimano RD M6000 Deore,10-speed
Front Derailleur
None
Shift Levers
Shimano Deore SLM-610, 10-speed
Cassette
SunRace CSMS2 TAY, 10-speed, 11-42 tooth
Crank
SR Suntour Zeron 1X, AX-S-BT, 170mm
Bottom Bracket
SR Suntour Euro, BSA
Chain
KMC, 10-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Front: NS Rotary 15, Boost 15x110 disc, sealed bearings, Rear: NS Rotary Cassette, 148x12mm Boost, sealed bearings
Rear Hub
Front: NS Rotary 15, Boost 15x110 disc, sealed bearings, Rear: NS Rotary Cassette, 148x12mm Boost, sealed bearings
Rims
Front: Octane One Solar 29", 32 hole, tubeless ready, Rear: Octane One Solar 27.5", 32 hole, tubeless ready
Spokes
14mm nipples
Tires
Front: Maxxis DHF 29x2.5" WT, EXO, TR, Rear: Maxxis Aggressor 27.5x2.5" WT, EXO, TR
Brakes
Brakes
Front: SRAM Level, 200mm rotor, Rear: SRAM Level, 180mm rotor
Brake Levers
SRAM Level
Cockpit
Stem
Octane One Tone 35, 45mm
Handlebar
NS Bar, 780mm, 20mm rise
Grips
NS Hold Fast
Headset
GW integrated tapered IS42/IS52, sealed bearings
Seat
Saddle
Octane One Rocker2
Seatpost
X-Fusion Manic, internal, 125mm on S/M, 150mm on L
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.38 mm | 1.32 mm |
| Front Center | 773 mm | 803 mm | 832 mm |
| Rake | 32 mm | 33 mm | 32 mm |
| Trail | 147 mm | 146 mm | 147 mm |
| Stack | 619 mm | 628 mm | 637 mm |
| Reach | 431 mm | 456 mm | 481 mm |
| Top Tube Length | 577 mm | 605 mm | 632 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 384 mm | 422 mm | 473 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1209 mm | 1239 mm | 1268 mm |
| Bottom Bracket Drop | -12 mm | -12 mm | -12 mm |
| Standover Height | 718 mm | 716 mm | 713 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Nerd HD completes the Ns Nerd model. There are 10 bikes that carry this model name. Take a sneak peek at all Ns Nerd bikes models from 2019, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Enduro bikes
If we make a quick analysis of the average weight of an Enduro bike, we get 14.27 kg (31.46 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
NS Nerd HD it’s weighing 14.9 kg (32.85 lbs). At this weight, is slightly heavier than average. In conclusion, the average Enduro bike weighs 4.41% less than Nerd HD.
Nerd HD components
Fork
The Nerd HD comes factory-installed with the X Fusion fork. This has a travel range of 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the X-Fusion 02 Pro RL rear shock model, which has a travel of 180mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The Nerd HD 2019 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. NS Nerd HD has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
NS Nerd HD bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
NS Nerd HD comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
