Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Manitou Machete Comp
-
Groupset NX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
Manitou Machete Comp
Rear Shock
Manitou Radium Expert, 190mm x 40mm
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12-speed, long cage
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle, 12-speed
Cassette
SRAM PG-1230, 12-speed 11-50 tooth
Crank
Truvativ Descendant PowerSpline, 170mm length
Bottom Bracket
SRAM PowerSpline BSA threaded
Chain
SRAM, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
NS, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
NS, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear
Rims
Octane One Solar, 32 hole, tubeless ready
Spokes
14mm nipples
Tires
Schwalbe Nobby Nic, 29" x 2.25"
Brakes
Brakes
SRAM Level, 180mm rotors
Brake Levers
SRAM Level
Cockpit
Stem
Octane One Tone, 35mm clamp, 45mm length
Handlebar
NS, 780mm width, 35mm bore, 20mm rise
Grips
NS Hold Fast
Headset
GW integrated tapered IS42/IS52, sealed bearings
Seat
Saddle
Octane One Rocker2
Seatpost
X-Fusion Manic internal dropper, 125mm or 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.37 mm | 1.32 mm |
| Bottom Bracket Height | 332 mm | 332 mm | 332 mm |
| Front Center | 729 mm | 757 mm | 786 mm |
| Rake | 51 mm | 50 mm | 50 mm |
| Trail | 104 mm | 105 mm | 105 mm |
| Stack | 608 mm | 617 mm | 626 mm |
| Reach | 424 mm | 449 mm | 474 mm |
| Top Tube Length | 577 mm | 604 mm | 632 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Chainstay Length | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1160 mm | 1188 mm | 1217 mm |
| Bottom Bracket Drop | 42 mm | 42 mm | 42 mm |
| Standover Height | 675 mm | 674 mm | 681 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Nerd Lite completes the Ns Nerd model. NS launched 10 bikes of this model so far. You can easily view all of the Ns Nerd bikes models from 2020, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Trail bikes average weight
Trail bikes have an average weight of 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
a bit heavier than average, Nerd Lite has a weight of 14 kg (30.86 lbs). To sum up, it’s 7.86% heavier than the average weight of Trail bikes.
Overview of components
Fork
The fork installed on this bike is the Manitou Machete Comp model. The travel on this model is 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is Manitou Radium Expert, with a travel distance of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When it comes to wheels, the Nerd Lite bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The Nerd Lite has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
NS Nerd Lite bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the Nerd Lite. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
