Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Apex -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NS AL6061-T6 custom formed and butted tubes, tapered integrated headtube, 142x12mm dropouts
Suspension Fork
NS Gravel+ full carbon fork, 15mm dropouts, NS thru axle
Drivetrain
Rear Derailleur
SRAM Apex type 2.1, long cage, 11spd
Shift Levers
SRAM Apex 11spd
Cassette
Sun Race CSMS7 11-42t
Crank
Rondo S:170mm, M:172.5mm, L:175mm 42t
Bottom Bracket
Shimano PF 86,5
Chain
SRAM, 11 spd
Pedals
-
Wheels
Front Hub
NS Bikes 100x15mm (sealed bearings)
Rear Hub
NS Bikes 142x12mm (sealed bearings)
Rims
Alex Draw 2.1P Asymmetrical, 32h, tubeless compatible
Spokes
butted 2.0-1.5-2.0 w/ 14mm nipples
Tires
Vittoria Mezcal III 700x45c
Brakes
Brakes
SRAM Apex hydraulic disc, 160mm rear & front
Cockpit
Stem
RAG+ Stem 31.8 S:80mm, M:90mm, L:100mm, XL:110mm, angle, - 8°
Handlebar
NS Flare 31.8, 420mm, 440mm, 460mm
Headset
GW integrated tapered IS42/52, sealed
Seat
Saddle
Selle Italia X3
Seatpost
Kalloy 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.46 mm | 1.47 mm | 1.5 mm |
| Bottom Bracket Height | 419 mm | 420 mm | 420 mm | 419 mm |
| Front Center | 609 mm | 615 mm | 636 mm | 656 mm |
| Rake | 2 mm | -3 mm | -2 mm | -1 mm |
| Trail | 128 mm | 127 mm | 126 mm | 125 mm |
| Stack | 533 mm | 576 mm | 599 mm | 627 mm |
| Reach | 386 mm | 394 mm | 407 mm | 417 mm |
| Top Tube Length | 552 mm | 567 mm | 588 mm | 606 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 475 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 69.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 125 mm | 145 mm | 170 mm | 200 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1033 mm | 1040 mm | 1062 mm | 1082 mm |
| Bottom Bracket Drop | -70 mm | -71 mm | -71 mm | -70 mm |
| Standover Height | 763 mm | 792 mm | 825 mm | 853 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Rag +1 completes the Ns Rag model. 6 bikes variations carry this model name so far. You can easily view all of the Ns Rag bikes models from 2022, here.
Model range prices
NS Rag JR 2022 is the most affordable bike of this model and has a price of 1379$. On the other hand, NS Rag +1 2022, is the most expensive and costs 2441$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2022 and its price was 2441$. Comparing the average cost of a Gravel bike to this one, you will see that Rag +1 price is 0.86% smaller.
Average weight for Gravel bikes
On a deeper look, we notice that the average weight of a Gravel bike is 8.13 kg (17.92 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 9.6 kg (21.16 lbs), NS bike is much heavier than average. In conclusion, the average Gravel bike weighs 18.08% less than Rag +1.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, NS Rag +1 2022, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
NS Rag +1 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
