Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Apex -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NS AL6061-T6 custom formed and butted tubes, tapered integrated headtube, 142x12mm dropouts
Suspension Fork
NS Gravel+ full carbon fork, 15mm dropouts, NS thru axle
Drivetrain
Rear Derailleur
SRAM Apex type 2.1, long cage, 11spd
Shift Levers
SRAM Apex 11spd
Cassette
Sun Race CSMS7 11-42t
Crank
Rondo S:170mm, M:172.5mm, L:175mm 42t
Bottom Bracket
Shimano PF 86,5
Chain
SRAM, 11 spd
Pedals
-
Wheels
Front Hub
NS Bikes 100x15mm (sealed bearings)
Rear Hub
NS Bikes 142x12mm (sealed bearings)
Rims
Alex Draw 2.1P Asymmetrical, 32h, tubeless compatible
Spokes
butted 2.0-1.5-2.0 w/ 14mm nipples
Tires
Vittoria Mezcal III 700x45c
Brakes
Brakes
SRAM Apex hydraulic disc, 160mm rear & front
Cockpit
Stem
RAG+ Stem 31.8 S:80mm, M:90mm, L:100mm, XL:110mm, angle, - 8°
Handlebar
NS Flare 31.8, 420mm, 440mm, 460mm
Headset
GW integrated tapered IS42/52, sealed
Seat
Saddle
Selle Italia X3
Seatpost
Kalloy 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.46 mm | 1.47 mm | 1.5 mm |
| Bottom Bracket Height | 419 mm | 420 mm | 420 mm | 419 mm |
| Front Center | 609 mm | 615 mm | 636 mm | 656 mm |
| Rake | 2 mm | -3 mm | -2 mm | -1 mm |
| Trail | 128 mm | 127 mm | 126 mm | 125 mm |
| Stack | 533 mm | 576 mm | 599 mm | 627 mm |
| Reach | 386 mm | 394 mm | 407 mm | 417 mm |
| Top Tube Length | 552 mm | 567 mm | 588 mm | 606 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 475 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 69.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 125 mm | 145 mm | 170 mm | 200 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1033 mm | 1040 mm | 1062 mm | 1082 mm |
| Bottom Bracket Drop | -70 mm | -71 mm | -71 mm | -70 mm |
| Standover Height | 763 mm | 792 mm | 825 mm | 853 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Rag +1 is part of the Ns Rag model. NS released 6 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
NS Rag JR 2023 is the most affordable bike of this model and has a price of 1379$. On the other hand, NS Rag +1 2023, is the most expensive and costs 2441$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, NS Rag +1 price was 2441$. Comparing this to the average Gravel bike price, we see that the price is 0.86% smaller.
Gravel bikes average weight
The average weight for Gravel bikes is 8.13 kg (17.92 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 9.6 kg (21.16 lbs), NS bike is much heavier than average. In short, the average Gravel bike weight is 18.08% lower than this one.
Rag +1 components
Fork material
Rag +1 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the Rag +1 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. NS Rag +1 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Rag +1 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
