Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox 35 Gold RL
-
Groupset NX Eagle, SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox 35 Gold RL, 110x15mm Boost thru-axle
Rear Shock
RockShox Deluxe Debonair RL, trunnion mount, 185mm x 55mm
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12-speed, long cage
Front Derailleur
N/A
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM PG-1210, 12-speed, 11-50 tooth
Crank
Truvativ Descendant DUB, 170mm length
Bottom Bracket
SRAM DUB BSA, 73mm threaded
Chain
SRAM, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
NS Rotary, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
NS Rotary, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear
Rims
Octane One Solar, 32 hole, tubeless ready
Spokes
14mm nipples
Tires
Maxxis Rekon, Dual compound, EXO, TR, 29" x 2.4" WT
Brakes
Brakes
SRAM Level, 2-piston, 180mm rotors
Brake Levers
SRAM Level
Cockpit
Stem
NS Tone, 35mm clamp, 45mm length
Handlebar
NS, 35mm bore, 780mm width, 20mm rise
Grips
NS Hold Fast Supersoft
Headset
GW integrated tapered IS42/IS52, sealed bearings
Seat
Saddle
Octane One Rocket2, CrMo hollow rails
Seatpost
X-Fusion Manic internal dropper, 125mm or 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.34 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm |
| Front Center | 738 mm | 767 mm | 797 mm |
| Rake | 43 mm | 43 mm | 44 mm |
| Trail | 120 mm | 120 mm | 119 mm |
| Stack | 616 mm | 625 mm | 634 mm |
| Reach | 424 mm | 449 mm | 474 mm |
| Top Tube Length | 596 mm | 624 mm | 653 mm |
| Seat Tube Angle | 74.6 ° | 74.5 ° | 74.4 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1168 mm | 1197 mm | 1227 mm |
| Bottom Bracket Drop | 37 mm | 37 mm | 37 mm |
| Standover Height | 725 mm | 723 mm | 738 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Snabb 130 is a Ns Snabb model. There are 18 bikes that carry this model name. Take a sneak peek at all Ns Snabb bikes models from 2020, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Trail bikes
If we make a quick analysis of the average weight of a Trail bike, we get 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
NS Snabb 130 it’s weighing 15.1 kg (33.29 lbs). At this weight, is much heavier than average. To sum up, it’s 16.33% heavier than the average weight of Trail bikes.
Overview of components
Fork
The fork installed on this bike is the RockShox 35 Gold RL model. The travel on this model is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the RockShox Deluxe Debonair RL rear shock model, which has a travel of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
As for the wheels, NS Snabb 130 2020, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
NS Snabb 130 bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The NS model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
