Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle, Race Face -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Performance 34 Grip, 3-position adjust with open mode adjust, tapered steerer, 15x110mm axle, 51mm offset
Rear Shock
FOX Performance Float, 3-position adjust, Trunnion mount, Evol LV, 185mm x 55mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, Type 3, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM XG-1275, 12-speed, 10-50 tooth
Crank
Race Face Aeffect SL, 170mm length
Bottom Bracket
Race Face Euro BSA
Chain
SRAM, 11-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Front: NS Rotary 15 Boost disc, sealed bearing, Rear: NS Rotary Cassette, 148x12mm Boost, sealed bearing
Rear Hub
Front: NS Rotary 15 Boost disc, sealed bearing, Rear: NS Rotary Cassette, 148x12mm Boost, sealed bearing
Rims
NS Enigma Roll, 32 hole, plus compatible, tubeless ready
Spokes
14g-2.0mm, 14mm nipples
Tires
Schwalbe Nobby Nic, folding, TL-Easy Addix, 29" x 2.35"
Brakes
Brakes
SRAM Guide R, 180mm Centerline rotors
Brake Levers
SRAM Guide R
Cockpit
Stem
NS Quantum Lite, 31.8mm clamp, 45mm length
Handlebar
NS Evidence Lite, 762mm width
Grips
NS Hold Fast
Headset
GW integrated, tapered IS42/52, sealed bearings
Seat
Saddle
Octane One Rocket, hollow cromoly rails
Seatpost
Kind Shock LEV Integra, 125mm travel (S), 150mm travel (M), 170mm travel (L)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.42 mm | 1.36 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm |
| Front Center | 730 mm | 758 mm | 787 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 107 mm | 107 mm | 107 mm |
| Stack | 613 mm | 622 mm | 632 mm |
| Reach | 414 mm | 439 mm | 464 mm |
| Top Tube Length | 584 mm | 613 mm | 643 mm |
| Seat Tube Angle | 74.6 ° | 74.5 ° | 74.4 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Chainstay Length | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1154 mm | 1183 mm | 1212 mm |
| Bottom Bracket Drop | 37 mm | 37 mm | 37 mm |
| Standover Height | 725 mm | 723 mm | 738 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Snabb 130 Plus 1 is part of the Ns Snabb model. NS released 18 bikes variations of this model so far. Take a sneak peek at all Ns Snabb bikes models from 2018, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Trail bikes average weight
If we make a quick analysis of the average weight of a Trail bike, we get 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 13.2 kg (29.1 lbs), NS bike is slightly heavier than average. In short, the average Trail bike weight is 1.69% lower than this one.
Overview of components
Fork
This bike has the Fox Performance Float 34 fork installed. The fork’s travel is 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The Snabb 130 Plus 1 has a rear shock with a travel of 130mm. The model FOX Performance Float is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The wheels on Snabb 130 Plus 1 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Snabb 130 Plus 1 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The NS model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
