Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Performance 34 Float Grip, sweep adjustment, 15x110mm Boost, 1.5" tapered steerer tube, 44 offset
Rear Shock
FOX Performace Float DPS, 3 position adjustment, EVOL LV, Trunnion mount, 185x55mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, type 3, 12-speed
Front Derailleur
None
Shift Levers
SRAM GX, 12-speed
Cassette
SRAM PG-1230, 12-speed, 11-50 tooth
Crank
Truvativ Descendant DUB, 170mm
Bottom Bracket
SRAM DUB, BSA
Chain
SRAM, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Front: NS Rotary 15, Boost 15x110 disc, sealed bearings, Rear: NS Rotary Cassette, 148x12mm Boost, sealed bearings
Rear Hub
Front: NS Rotary 15, Boost 15x110 disc, sealed bearings, Rear: NS Rotary Cassette, 148x12mm Boost, sealed bearings
Rims
NS Enigma Roll 29", 32 hole, tubeless ready
Spokes
14mm nipples
Tires
WTB Trail Boss 2 29x2.4", foldable bead, TCS light/fast rolling dual DNA compound, lightweight skinwall
Brakes
Brakes
SRAM Guide R, 180mm rotors
Brake Levers
SRAM Guide R
Cockpit
Stem
NS Quantum Lite 35, 45mm
Handlebar
NS Licence 35, 780mm
Grips
NS Hold Fast
Headset
GW integrated tapered IS42/IS52, sealed bearings
Seat
Saddle
Octane One Crit, CrMo hollow rails
Seatpost
X-Fusion Manic, internal, 125mm on S/M, 150mm on L
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.34 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm |
| Front Center | 738 mm | 767 mm | 797 mm |
| Rake | 43 mm | 43 mm | 44 mm |
| Trail | 120 mm | 120 mm | 119 mm |
| Stack | 616 mm | 625 mm | 634 mm |
| Reach | 424 mm | 449 mm | 474 mm |
| Top Tube Length | 596 mm | 624 mm | 653 mm |
| Seat Tube Angle | 74.6 ° | 74.5 ° | 74.4 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1168 mm | 1197 mm | 1227 mm |
| Bottom Bracket Drop | 37 mm | 37 mm | 37 mm |
| Standover Height | 725 mm | 723 mm | 738 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Snabb 130 Plus 1 is part of the Ns Snabb model. NS released 18 bikes variations of this model so far. Take a sneak peek at all Ns Snabb bikes models from 2019, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Trail bikes
Trail bikes weigh an average of 12.98 kg (28.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
NS Snabb 130 Plus 1 it’s weighing 14.3 kg (31.53 lbs). At this weight, is considerably heavier than average. To sum up, it’s 10.17% heavier than the average weight of Trail bikes.
Snabb 130 Plus 1 components
Fork
The fork installed on this bike is the Fox Performance Float 34 model. The travel on this model is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The Snabb 130 Plus 1 has a rear shock with a travel of 130mm. The model FOX Performace Float DPS is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the Snabb 130 Plus 1 bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. NS Snabb 130 Plus 1 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Snabb 130 Plus 1 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
NS Snabb 130 Plus 1 includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
