Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Performance Float 36
-
Groupset GX Eagle, NX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Performance 36 Float Grip, 3 position adjustment with open mode adjustment, 15x110mm Boost, 1.5" tapered steerer tube, 44 offset
Rear Shock
FOX Performace Float DPX2, 3 position adjustment, EVOL LV, Trunnion mount, 205x65mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, type 3, 12-speed
Front Derailleur
None
Shift Levers
SRAM NX, 12-speed
Cassette
SRAM PG-1230, 12-speed, 11-50 tooth
Crank
Truvativ Descendant DUB, 170mm
Bottom Bracket
SRAM DUB, BSA
Chain
SRAM, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Front: NS Rotary 15, Boost 15x110 disc, sealed bearings, Rear: NS Rotary Cassette, 148x12mm Boost, sealed bearings
Rear Hub
Front: NS Rotary 15, Boost 15x110 disc, sealed bearings, Rear: NS Rotary Cassette, 148x12mm Boost, sealed bearings
Rims
Front: NS Enigma Roll 27.5", 32 hole, tubeless ready, Rear: NS Enigma Rock 27.5", 32 hole, tubeless ready
Spokes
14mm nipples
Tires
Front: Schwalbe Magic Mary 27.5x2.35", folding, TLE, Rear: Schwalbe Nobby Nic 27.5x2.35", folding, TLE
Brakes
Brakes
Front: SRAM Guide R, 200mm rotor, Rear: SRAM Guide R, 180mm rotor
Brake Levers
SRAM Guide R
Cockpit
Stem
NS Quantum Lite 35, 45mm
Handlebar
NS Licence 35, 800mm
Grips
NS Hold Fast
Headset
GW integrated tapered IS42/IS52, sealed bearings
Seat
Saddle
Octane One Crit, CrMo hollow rails
Seatpost
X-Fusion Manic, internal, 125mm on S/M, 150mm on L
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 367 mm | 367 mm | 367 mm |
| Front Center | 748 mm | 778 mm | 807 mm |
| Rake | 30 mm | 30 mm | 30 mm |
| Trail | 133 mm | 133 mm | 133 mm |
| Stack | 594 mm | 603 mm | 612 mm |
| Reach | 424 mm | 449 mm | 474 mm |
| Top Tube Length | 571 mm | 599 mm | 627 mm |
| Seat Tube Angle | 75.6 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1172 mm | 1202 mm | 1231 mm |
| Bottom Bracket Drop | -12 mm | -12 mm | -12 mm |
| Standover Height | 745 mm | 745 mm | 746 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Snabb 160 1 belongs to the Ns Snabb model. 18 bikes variations carry this model name so far. Check out the entire range from 2019 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Enduro bikes
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Enduro bikes average weight
The average weight for Enduro bikes is 14.27 kg (31.46 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 14.1 kg (31.09 lbs), NS bike is slightly lighter than average. To sum up, it’s 1.21% lighter than the average weight of Enduro bikes.
Snabb 160 1 components
Fork
The Fox Performance Float 36 is included from the factory. It has a travel distance of 170mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
NS Snabb 160 1 bike has the FOX Performace Float DPX2 model installed, and has a travel of 160mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When it comes to wheels, the Snabb 160 1 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Snabb 160 1 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
Dropper post
The NS model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
