Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Factory Float 36
-
Groupset X01 Eagle, Race Face -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX Factory 36 Float FIT RC2, Kashima coating, HSC, LSC, tapered steerer, 15x110mm axle, 44mm offset
Rear Shock
FOX Factory Float DPX2, 3-position adjust, Trunnion mount, Evol LV, 205mm x 65mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle, Type 3, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM X01 Eagle, 12-speed
Cassette
SRAM CS XG-1295 Eagle, 12-speed
Crank
Race Face Next R, 170mm length
Bottom Bracket
Race Face BB92 PressFit
Chain
SRAM, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Front: NS Rotary 15 Boost disc, sealed bearing, Rear: NS Rotary Cassette, 142mm, sealed bearing
Rear Hub
Front: NS Rotary 15 Boost disc, sealed bearing, Rear: NS Rotary Cassette, 142mm, sealed bearing
Rims
NS Enigma Roll (front), NS Enigma Rock (rear)
Spokes
14g-2.0mm, 14mm nipples
Tires
Front: Schwalbe Magic Mary, folding, TL-Easy, 27.5" x 2.35", Rear: Schwalbe Nobby Nic, folding, TL-Easy, 27.5" x 2.35"
Brakes
Brakes
SRAM Guide RS, Centerline rotors, 200mm front, 180mm rear
Brake Levers
SRAM Guide RS
Cockpit
Stem
NS Quantum Lite, 31.8mm clamp, 45mm length
Handlebar
NS Monogram Plus, 780mm width
Grips
NS Hold Fast
Headset
NS custom tapered, EX44/56, angleset (1°), sealed bearing
Seat
Saddle
Octane One Crit, Ti-Alloy rails
Seatpost
RockShox Reverb Stealth, 150mm travel (M), 170mm travel (L)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.32 mm |
| Bottom Bracket Height | 344 mm | 344 mm |
| Front Center | 755 mm | 784 mm |
| Rake | 28 mm | 28 mm |
| Trail | 135 mm | 135 mm |
| Stack | 609 mm | 618 mm |
| Reach | 443 mm | 468 mm |
| Top Tube Length | 601 mm | 629 mm |
| Seat Tube Angle | 75.5 ° | 75.4 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 65 ° | 65 ° |
| Head Tube Length | 120 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm |
| Wheelbase | 1185 mm | 1214 mm |
| Bottom Bracket Drop | 11 mm | 11 mm |
| Standover Height | 816 mm | 823 mm |
| Wheels | 27" | 27" |
Model Overview
Snabb 160 C 1 is part of the Ns Snabb model. There are 18 bikes that carry this model name. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Enduro bikes average price
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Enduro bikes average weight
On a deeper look, we notice that the average weight of an Enduro bike is 14.27 kg (31.46 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 12.9 kg (28.44 lbs), NS bike is considerably lighter than average. In other words, this model is 10.62% lighter than the average Enduro bike.
Overview of components
Fork
The Fox Factory Float 36 is included from the factory. It has a travel distance of 170mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
NS Snabb 160 C 1 bike has the FOX Factory Float DPX2 model installed, and has a travel of 160mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, NS Snabb 160 C 1 2018, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Dropper post
The NS model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
