Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Travel Front 100mm -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
114cm - 132cm
MD
124cm - 137cm
LG
134cm - 152cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Nukeproof Cub-Scout 20”, custom butted hydro-formed 6061 Alloy, internal cable routing for dropper seat post, threaded bottom bracket, 142mm Bolt-thru rear axle spacing
Suspension Fork
Nukeproof Cub-Scout 20”+ Fork, custom butted hydro-formed 6061 Alloy, 1 1/8th Steerer, 40mm Offset, 15x100mm Bolt-thru Axle
Drivetrain
Cassette
Sunrace CSM55 8-Speed, 11-34T
Crank
Samox Square Taper 127mm, 32T
Bottom Bracket
BSA, threaded
Wheels
Rims
Joytec D951-15 15x100mm hub on WTB STi30 20" TCS Rim
Tires
Front & Rear: Vee Rubber Crown Gem 20" x 2.6” Skinwall
Brakes
Brakes
Tektro M276 Kids Specific Hydraulic Brakes
Disk Rotors
Tektro Wave, 160mm
Cockpit
Stem
Nukeproof, 40mm, black
Handlebar
Nukeproof Neutron Jr 600mm Wide, 15mm Rise, 31.8mm Clamp
Grips
Nukeproof Jr Single Clamp lock on, 115mm Long, Soft Compound
Headset
Nukeproof Warhead, 44-44 IESS
Seat
Saddle
Nukeproof Neutron Jr, Black
Seatpost
Nukeproof Neutron Jr, Black, 27.2mm, 300mm Long, 0 Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.63 mm | 1.62 mm |
| Front Center | 542 mm | 592 mm | 661 mm |
| Rake | 38 mm | 38 mm | 46 mm |
| Stack | 468.5 mm | 543 mm | 593 mm |
| Reach | 312 mm | 334 mm | 367 mm |
| Top Tube Length | 460 mm | 504.5 mm | 551 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 265 mm | 320 mm | 360 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm |
| Chainstay Length | 356 mm | 406 mm | 421 mm |
| Wheelbase | 895 mm | 994 mm | 1077 mm |
| Bottom Bracket Drop | 35 mm | 45 mm | 47 mm |
| Front Travel | 80 mm | 100 mm | 120 mm |
| Wheels | 20" | 20" | 20" |
| Rider Min Height | 114 cm | 124 cm | 134 cm |
| Rider Max Height | 132 cm | 137 cm | 152 cm |
About this model
Cub Scout 20? Sport completes the Nukeproof Cub model. Nukeproof released 34 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Mountain bikes average price
If you want to purchase a solid Mountain bike, it is important to know that the average cost is 616$. However, you could also get a good Mountain bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Mountain bikes
On a deeper look, we notice that the average weight of a Mountain bike is 11.4 kg (25.13 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 10.9 kg (24.03 lbs), Nukeproof bike is slightly lighter than average. In conclusion, the average Mountain bike weighs 4.59% more than Cub Scout 20? Sport.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
Cub Scout 20? Sport has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
When leaving the production line, the Cub Scout 20? Sport model has 20″ aluminum wheels. The 20″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 114 cm – 152 cm (3.74 ft – 4.99 ft). In short, you can easily find one that suits you.
