Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" / 20" -
Travel Front 100mm -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
114cm - 132cm
MD
124cm - 137cm
LG
134cm - 152cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Nukeproof Cub-Scout 24”, custom butted hydro-formed 6061 Alloy, internal cable routing for dropper seat post, threaded bottom bracket, 142mm Bolt-thru rear axle spacing
Suspension Fork
Spinner 300 24-15 Air Suspension forks, 1 1/8th Steerer, 42mm Offset, 15x100mm Bolt-thru Axle
Drivetrain
Cassette
Sunrace CSM55 8-Speed, 11-34T
Crank
Samox Square Taper 140mm, 30T
Bottom Bracket
BSA, threaded
Wheels
Rims
Joytec D951-15 15x100mm hub on WTB STi30 24" TCS Rim
Tires
Front & Rear: Vee Rubber Crown Gem 20" x 2.6” Skinwall
Brakes
Brakes
Tektro M276 Kids Specific Hydraulic Brakes
Disk Rotors
Tektro Wave, 160mm
Cockpit
Stem
Nukeproof, 50mm, black
Handlebar
Nukeproof Neutron Jr 640mm Wide, 15mm Rise, 31.8mm Clamp
Grips
Nukeproof Jr Single Clamp lock on, 115mm Long, Soft Compound
Headset
Nukeproof Warhead, 44-44 IESS
Seat
Saddle
Nukeproof Neutron Jr, Black
Seatpost
Nukeproof Neutron Jr, Black, 27.2mm, 300mm Long, 0 Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.63 mm | 1.62 mm |
| Front Center | 542 mm | 592 mm | 661 mm |
| Rake | 38 mm | 38 mm | 46 mm |
| Stack | 468.5 mm | 543 mm | 593 mm |
| Reach | 312 mm | 334 mm | 367 mm |
| Top Tube Length | 460 mm | 504.5 mm | 551 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 265 mm | 320 mm | 360 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm |
| Chainstay Length | 356 mm | 406 mm | 421 mm |
| Wheelbase | 895 mm | 994 mm | 1077 mm |
| Bottom Bracket Drop | 35 mm | 45 mm | 47 mm |
| Front Travel | 80 mm | 100 mm | 120 mm |
| Wheels | 24" | 24" | 24" |
| Rider Min Height | 114 cm | 124 cm | 134 cm |
| Rider Max Height | 132 cm | 137 cm | 152 cm |
About this model
Cub Scout 24? Sport is part of the Nukeproof Cub model. Nukeproof launched 34 bikes of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Mountain bikes average price
According to our math, the average price for a trustworthy Mountain bike is 616$. However, this doesn’t mean that if you spend less money on a Mountain bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Mountain bikes average weight
Mountain bikes have an average weight of 11.4 kg (25.13 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Cub Scout 24? Sport weighs 12.3 kg (27.12 lbs) and is a bit heavier than the average. In conclusion, the average Mountain bike weighs 7.89% less than Cub Scout 24? Sport.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Cub Scout 24? Sport components
Wheels size
The wheels on Cub Scout 24? Sport are the 24″ aluminum type. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Cub Scout 24? Sport comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Nukeproof Cub Scout 24? Sport bike has 3 sizes, in the range of 114 cm – 152 cm (3.74 ft – 4.99 ft). In conclusion, finding one for you shouldn’t be a problem.
