Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Suspension Hardtail
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom triple butted hydro-formed Alloy
Cockpit
Headset
Nukeproof, 44-56 IITS
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XXL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.43 mm | 1.39 mm | 1.36 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 307 mm | 307 mm |
| Front Center | 763.5 mm | 785.2 mm | 806.8 mm | 828.4 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 132.33 mm | 132.33 mm | 132.33 mm | 132.33 mm |
| Stack | 635.2 mm | 644.2 mm | 653.3 mm | 662.3 mm |
| Reach | 433.8 mm | 451.3 mm | 468.7 mm | 486.1 mm |
| Top Tube Length | 617.7 mm | 638 mm | 658 mm | 678 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 410 mm | 440 mm | 460 mm | 480 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 425 mm | 428 mm | 430 mm | 433 mm |
| Wheelbase | 1180 mm | 1204 mm | 1228 mm | 1252 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 684 mm | 700 | 704 mm | 708 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
Scout 290 Frame completes the Nukeproof Scout model. There are 35 frames that carry this model name. Take a sneak peek at all Nukeproof Scout frames models from 2022, by clicking here.
Model range prices
The most economical model, the Nukeproof Scout 290 Frame 2022 has a starting price of 499$. Nukeproof Scout 290 Frame Only 2022 on the other hand is the most expensive at 607$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail frames
Our math shows that the average cost of a dependable Trail frame is 1736$. However, this doesn’t mean that if you spend less money on a Trail frame, you couldn’t get a decent one. In short, before purchasing your ideal frame do some research about its components, and also check for reviews online.
This frame was released in 2022 and its price was 499$. In conclusion, this frame price is 247.9% lower than the price of the average Trail frame.
