Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
XS
156cm - 166cm
SM
163cm - 174cm
SM
163cm - 174cm
MD
171cm - 182cm
MD
171cm - 182cm
LG
179cm - 189cm
LG
179cm - 189cm
XL
185cm - 195cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
Obed Carbon
Drivetrain
Rear Derailleur
Shimano 105 R7000
Front Derailleur
Shimano 105 R7000
Shift Levers
Shimano R7020
Cassette
Shimano HG700 11-34
Crank
Shimano 105 R7000 50/34
Bottom Bracket
Pressfit BB86
Chain
Shimano HG601
Pedals
Not Included
Wheels
Rims
Select Wheels Above
Tires
Panaracer Gravel King 700x32c
Brakes
Brakes
Shimano 105
Disk Rotors
Shimano RT64 160mm
Cockpit
Stem
FSA Gossamer
Handlebar
FSA Gossamer Wing Compact
Headset
Cane Creek 40 Series
Seat
Saddle
WTB SL8 Comp Steel Rail
Seatpost
FSA Gossamer Alloy 20mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM | MD | MD | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.44 mm | 1.48 mm | 1.48 mm | 1.5 mm | 1.5 mm | 1.53 mm | 1.53 mm | 1.54 mm | 1.54 mm |
| Bottom Bracket Height | 269 mm | mm | 269 mm | mm | 269 mm | mm | 269 mm | mm | 269 mm | mm |
| Front Center | 594 mm | 594 mm | 595 mm | 595 mm | 600 mm | 600 mm | 611 mm | 611 mm | 626 mm | 626 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 67 mm | 60 mm | 69 mm | 63 mm | 61 mm | 54 mm | 58 mm | 51 mm | 58 mm | 51 mm |
| Stack | 542 mm | 542 mm | 562 mm | 562 mm | 573 mm | 573 mm | 595 mm | 595 mm | 614 mm | 614 mm |
| Reach | 376 mm | 376 mm | 380 mm | 380 mm | 381 mm | 381 mm | 390 mm | 390 mm | 399 mm | 399 mm |
| Top Tube Length | 525 mm | 525 mm | 540 mm | 540 mm | 555 mm | 555 mm | 570 mm | 570 mm | 585 mm | 585 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 490 mm | 520 mm | 520 mm | 540 mm | 540 mm | 560 mm | 560 mm | 580 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 120 mm | 140 mm | 140 mm | 150 mm | 150 mm | 170 mm | 170 mm | 190 mm | 190 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1025 mm | 1025 mm | 1026 mm | 1026 mm | 1031 mm | 1031 mm | 1042 mm | 1042 mm | 1057 mm | 1057 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 754 mm | 754 mm | 781 mm | 781 mm | 798 mm | 798 mm | 818 mm | 818 mm | 838 mm | 838 mm |
| Wheels | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 |
| Rider Min Height | 156 cm | 156 cm | 163 cm | 163 cm | 171 cm | 171 cm | 179 cm | 179 cm | 185 cm | 185 cm |
| Rider Max Height | 166 cm | 166 cm | 174 cm | 174 cm | 182 cm | 182 cm | 189 cm | 189 cm | 195 cm | 195 cm |
About this model
Baseline 105 is part of the Obed Baseline model. Obed launched 13 bikes of this model so far. Take a sneak peek at all Obed Baseline bikes models from 2022, by clicking here.
Model range prices
Obed Baseline 105 2022 is the cheapest bike model and costs 2845$. Obed Baseline Ultegra Di2 2022 is the most expensive one and costs 4295$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Endurance bikes
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2845$. Doing a quick comparison, we notice that Baseline 105 price is 21.27% higher than the average cost of an Endurance bike.
Baseline 105 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the Baseline 105 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Baseline 105 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 10 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
