Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX Di2, GRX 800 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
XS
156cm - 166cm
SM
163cm - 174cm
SM
163cm - 174cm
MD
171cm - 182cm
MD
171cm - 182cm
LG
179cm - 189cm
LG
179cm - 189cm
XL
185cm - 195cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
GVR Carbon
Drivetrain
Rear Derailleur
Shimano GRX RX815 Di2
Front Derailleur
Shimano GRX RX815 Di2
Shift Levers
Shimano GRX RX815 Di2
Cassette
Ultegra HG800 11-34
Crank
GRX RX810 48/31
Bottom Bracket
Praxis T47
Chain
Shimano HG701
Pedals
Not Included
Wheels
Rims
Select Wheels Above
Tires
Select Tires From Options Above
Brakes
Brakes
Shimano GRX RX810 Hydraulic
Disk Rotors
Shimano XT MT800 160mm
Cockpit
Stem
FSA NS ACR
Handlebar
FSA A-Wing AGX Alloy ACR
Headset
FSA 55R 1.5" ACR
Seat
Saddle
Select Saddle From Options Above
Seatpost
FSA SL-K Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM | MD | MD | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.45 mm | 1.47 mm | 1.47 mm | 1.51 mm | 1.51 mm | 1.54 mm | 1.54 mm | 1.56 mm | 1.56 mm |
| Bottom Bracket Height | 277 mm | mm | 277 mm | mm | 278 mm | mm | 281 mm | mm | 282 mm | mm |
| Front Center | 596 mm | 596 mm | 601 mm | 601 mm | 600 mm | 600 mm | 611 mm | 611 mm | 628 mm | 628 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 66 mm | 60 mm | 69 mm | 63 mm | 68 mm | 62 mm | 62 mm | 56 mm | 62 mm | 56 mm |
| Stack | 526 mm | 526 mm | 540 mm | 540 mm | 562 mm | 562 mm | 582 mm | 582 mm | 602 mm | 602 mm |
| Reach | 362 mm | 362 mm | 367 mm | 367 mm | 372 mm | 372 mm | 377 mm | 377 mm | 387 mm | 387 mm |
| Top Tube Length | 510 mm | 510 mm | 519 mm | 519 mm | 536 mm | 536 mm | 552 mm | 552 mm | 573 mm | 573 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 460 mm | 490 mm | 490 mm | 520 mm | 520 mm | 550 mm | 550 mm | 580 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 115 mm | 115 mm | 128 mm | 128 mm | 146 mm | 146 mm | 170 mm | 170 mm | 192 mm | 192 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 1002 mm | 1002 mm | 1008 mm | 1008 mm | 1006 mm | 1006 mm | 1018 mm | 1018 mm | 1035 mm | 1035 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 71 mm | 71 mm | 68 mm | 68 mm | 67 mm | 67 mm |
| Standover Height | 737 mm | 737 mm | 761 mm | 761 mm | 799 mm | 799 mm | 829 mm | 829 mm | 855 mm | 855 mm |
| Wheels | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 |
| Rider Min Height | 156 cm | 156 cm | 163 cm | 163 cm | 171 cm | 171 cm | 179 cm | 179 cm | 185 cm | 185 cm |
| Rider Max Height | 166 cm | 166 cm | 174 cm | 174 cm | 182 cm | 182 cm | 189 cm | 189 cm | 195 cm | 195 cm |
Model Overview
GVR GRX 810 Di2 is part of the Obed Gvr model. Obed launched 15 bikes of this model so far. Take a sneak peek at all Obed Gvr bikes models from 2022, by clicking here.
Model range prices
Obed GVR GRX 600 2022 is the cheapest bike model and costs 3395$. Obed GVR Campy Ekar 1×13 2022 is the most expensive one and costs 4945$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Obed GVR GRX 810 Di2 price was 4595$. In conclusion, this bike price is 86.64% higher than the price of the average Gravel bike.
Overview of components
Fork material
GVR GRX 810 Di2 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Obed GVR GRX 810 Di2 2022, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 10 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
