Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c / 650b -
Groupset GRX Di2, GRX 800 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
XS
156cm - 166cm
SM
163cm - 174cm
SM
163cm - 174cm
MD
171cm - 182cm
MD
171cm - 182cm
LG
179cm - 189cm
LG
179cm - 189cm
XL
185cm - 195cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
Boundary Carbon, Multiple Rack/Fender/Cargo Mounts
Drivetrain
Rear Derailleur
Shimano GRX RX815 Di2
Front Derailleur
Shimano GRX RX815 Di2
Shift Levers
Shimano GRX RX815 Di2
Cassette
Ultegra HG800 11-34
Crank
Shimano GRX RX810 48x31
Bottom Bracket
Shimano BB86
Chain
Shimano HG701
Wheels
Rims
Select Wheels Above
Tires
Panaracer Gravel King SK 700x43c Tubeless or Panaracer Gravel King SK 650X48c Tubeless
Brakes
Brakes
Shimano GRX RX810 Hydraulic
Disk Rotors
Shimano XT MT800 160mm
Cockpit
Stem
Easton EA70 31.8
Handlebar
Easton EA70AX
Headset
Cane Creek 40 Series
Seat
Saddle
WTB Volt Medium Cromoly
Seatpost
Easton EA70 Zero Setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM | MD | MD | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.44 mm | 1.48 mm | 1.48 mm | 1.5 mm | 1.5 mm | 1.53 mm | 1.53 mm | 1.54 mm | 1.54 mm |
| Bottom Bracket Height | 282 mm | mm | 282 mm | mm | 282 mm | mm | 282 mm | mm | 282 mm | mm |
| Front Center | 594 mm | 594 mm | 595 mm | 595 mm | 600 mm | 600 mm | 611 mm | 611 mm | 626 mm | 626 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 64 mm | 73 mm | 66 mm | 64 mm | 58 mm | 61 mm | 55 mm | 61 mm | 55 mm |
| Stack | 542 mm | 542 mm | 562 mm | 562 mm | 573 mm | 573 mm | 595 mm | 595 mm | 614 mm | 614 mm |
| Reach | 376 mm | 376 mm | 380 mm | 380 mm | 381 mm | 381 mm | 390 mm | 390 mm | 399 mm | 399 mm |
| Top Tube Length | 525 mm | 525 mm | 540 mm | 540 mm | 555 mm | 555 mm | 570 mm | 570 mm | 585 mm | 585 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 490 mm | 520 mm | 520 mm | 540 mm | 540 mm | 560 mm | 560 mm | 580 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 120 mm | 140 mm | 140 mm | 150 mm | 150 mm | 170 mm | 170 mm | 190 mm | 190 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1025 mm | 1025 mm | 1026 mm | 1026 mm | 1031 mm | 1031 mm | 1042 mm | 1042 mm | 1057 mm | 1057 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 764 mm | 764 mm | 791 mm | 791 mm | 808 mm | 808 mm | 828 mm | 828 mm | 848 mm | 848 mm |
| Wheels | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 |
| Rider Min Height | 156 cm | 156 cm | 163 cm | 163 cm | 171 cm | 171 cm | 179 cm | 179 cm | 185 cm | 185 cm |
| Rider Max Height | 166 cm | 166 cm | 174 cm | 174 cm | 182 cm | 182 cm | 189 cm | 189 cm | 195 cm | 195 cm |
About this model
Boundary GRX 810 Di2 belongs to the Ocoee Boundary model. Ocoee launched 8 bikes of this model so far. You can easily view all of the Ocoee Boundary bikes models from 2020, here.
Model range prices
The most economical model, the Ocoee Boundary GRX 400 2020 has a starting price of 2399$. Ocoee Boundary GRX 810 Di2 2020 on the other hand is the most expensive at 4050$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2020 for 4050$. Comparing the average cost of a Gravel bike to this one, you will see that Boundary GRX 810 Di2 price is 64.5% more expensive.
Boundary GRX 810 Di2 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, Ocoee Boundary GRX 810 Di2 2020, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Boundary GRX 810 Di2 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 10 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
