Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 130mm -
Fork RockShox Judy Silver TK
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Rockshox Judy Silver TK 29" Boost Fork / 130mm / 15x110mm / Gloss Black / Crown Adjust
Drivetrain
Rear Derailleur
SRAM SX Eagle Rear Mech / 12 Speed
Cassette
SRAM PG-1210 Eagle 12 Speed Cassette / 11-50
Crank
SRAM SX Eagle DUB Crankset / 170mm / 32 Tooth / BOOST
Bottom Bracket
SRAM DUB BSA Bottom Bracket / 73mm
Chain
SRAM SX Eagle 12 Speed Chain / 126 Link
Wheels
Rims
Alex EXR30 29er on Formula Boost 6 Bolt Wheelset / Shimano 11 Speed
Tires
Panaracer FireSport 29" Wire Bead Tyre / 2.35"
Brakes
Brakes
SRAM Level Hydraulic Disc Brake / Front / 900mm / Post Mount 20mm Spacers
Cockpit
Stem
On-One Hot Box V2 Stem / 60mm / 7 Degree / 31.8mm
Handlebar
On-One Enduro6 Riser Handlebar / 780mm
Grips
On-One Knurl Grip / Black
Seat
Saddle
San Marco Monza Start Saddle / Black / Carbon Steel
Seatpost
On-One Twelfty V2 6061 Alloy Seatpost / 31.6mm / 400mm / Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LRG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.39 mm | 1.37 mm | 1.34 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm | 316 mm |
| Front Center | 725 mm | 762 mm | 779 mm | 807 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 117 mm | 116 mm | 117 mm | 116 mm |
| Stack | 606 mm | 616 mm | 625 mm | 638 mm |
| Reach | 412 mm | 443 mm | 457 mm | 477 mm |
| Top Tube Length | 577 mm | 612 mm | 627 mm | 652 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 135 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1166 mm | 1203 mm | 1220 mm | 1248 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Big Dog SRAM SX is an Onone Big Dog model. There are 10 bikes that carry this model name. You can easily view all of the Onone Big Dog bikes models from 2020, here.
Model range prices
On-One Big Dog SRAM SX 2020 is the most affordable bike of this model and has a price of 1215$. On the other hand, On-One Big Dog SRAM GX 2020, is the most expensive and costs 1458$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2020 and its price was 1215$. If we compare this with the average Trail bike cost we notice that the price is 127.33% lower.
Big Dog SRAM SX components
Fork
On-One Big Dog SRAM SX 2020 bike is equipped with the RockShox Judy Silver TK fork, and has 130mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The wheels on Big Dog SRAM SX are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. On-One Big Dog SRAM SX has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
