Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Groupset SX Eagle -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Flat out fast carbon XC hardtail for alloy money. 1200g Toray T700 carbon fibre frame. Race responsive 69.5º head angle geometry. Dropper post, double bottle and 29x2.3 tyre compatible.
Suspension Fork
Selcof Carbon 27.5+ or 29er Fork / Matt Black
Drivetrain
Rear Derailleur
SRAM SX Eagle Rear Mech / 12 Speed
Cassette
SRAM PG-1210 Eagle 12 Speed Cassette / 11-50
Crank
SRAM SX Eagle DUB Crankset / 170mm / 32 Tooth / BOOST
Bottom Bracket
SRAM DUB BSA Bottom Bracket / 73mm
Chain
SRAM SX Eagle 12 Speed Chain / 126 Link
Wheels
Rims
Alex EXR30 29er on Formula Boost 6 Bolt Wheelset / Shimano 11 Speed
Tires
Panaracer FireSport 29" Wire Bead Tyre / 2.35"
Brakes
Brakes
SRAM Level Hydraulic Disc Brake / Front / 900mm / Post Mount 20mm Spacers
Cockpit
Stem
On-One Hot Box V2 Stem / 60mm / 7 Degree / 31.8mm
Handlebar
On-One Enduro6 Riser Handlebar / 780mm
Grips
On-One Knurl Grip / Black
Seat
Saddle
San Marco Monza Start Saddle / Black / Carbon Steel
Seatpost
On-One Twelfty V2 6061 Alloy Seatpost / 31.6mm / 400mm / Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | 19" | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.44 mm | 1.41 mm | 1.37 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 659 mm | 684 mm | 710 mm | 736 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 101 mm | 90 mm | 89 mm | 87 mm |
| Stack | 602 mm | 605 mm | 620 mm | 630 mm |
| Reach | 407 mm | 420 mm | 440 mm | 460 mm |
| Top Tube Length | 570 mm | 595 mm | 620 mm | 645 mm |
| Seat Tube Angle | 73.7 ° | 73.7 ° | 74.7 ° | 73.7 ° |
| Seat Tube Length | 395 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 95 mm | 100 mm | 115 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1082 mm | 1107 mm | 1133 mm | 1159 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Whippet SRAM SX belongs to the Onone Whippet model. On-One released 13 bikes variations of this model so far. Take a sneak peek at all Onone Whippet bikes models from 2020, by clicking here.
Model range prices
On-One Whippet SRAM SX 2020 is the cheapest bike model and costs 1215$. On-One Whippet Shimano SLX 2020 is the most expensive one and costs 1823$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1215$. Doing a quick comparison, we notice that Whippet SRAM SX price is 56.79% smaller than the average cost of a Crosscountry bike.
Whippet SRAM SX components
Fork material
Whippet SRAM SX has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, On-One Whippet SRAM SX 2020, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
