Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 170cm
MD
167cm - 180cm
LG
177cm - 190cm
XL
188cm - 203cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Your choice, U.P.: 8.2kg (Medium, 700c, with inner tubes), WI.DE.: 8.2kg (Medium, 700c, with inner tubes), U.P.P.E.R.: 8.0kg (Medium, 700c, with inner tubes)
Drivetrain
Rear Derailleur
Campagnolo Ekar 13-speed
Shift Levers
Campagnolo Ekar hydraulic
Cassette
Campagnolo Ekar 9-42T 13-speed
Crank
Campagnolo Ekar 170mm (XS/S), 172.5mm (M), 175mm (L & XL)
Bottom Bracket
Campagnolo Pro-Tech BB386EVO
Chain
Campagnolo Ekar 13-speed
Wheels
Rims
HED Emporia GA Pro 650b, HED Emporia GA Pro 700c, ENVE AG25 gravel 700c
Tires
Pirelli Cinturato Gravel H 700x40c, Vittoria Peyote/Barzo 27.5x2.1”
Brakes
Brakes
Campagnolo Ekar hydraulic with 160mm rotors
Cockpit
Stem
ENVE Road, 80 (S)/90 (M)/100 (L)/110 (XL)mm
Handlebar
ENVE SES AR Road, 40 (S)/42 (M)/44cm (L&XL)
Headset
included in your frameset of choice
Seat
Saddle
fi'zi:k Tempo Argo R5-150mm, black
Seatpost
ENVE 0-offset, 27,2, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.53 mm | 1.55 mm | 1.56 mm | 1.58 mm |
| Bottom Bracket Height | 269 mm | 272 mm | 274 mm | 274 mm | 274 mm |
| Stack | 516 mm | 541 mm | 566 mm | 591 mm | 616 mm |
| Reach | 342 mm | 354 mm | 366 mm | 378 mm | 390 mm |
| Top Tube Length | 486 mm | 511 mm | 536 mm | 556 mm | 576 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 464 mm | 495 mm | 530 mm | 550 mm | 564 mm |
| Head Tube Angle | 68 ° | 69 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 99 mm | 125 mm | 150 mm | 170 mm | 196 mm |
| Wheelbase | 986 mm | 1000 mm | 1005 mm | 1018 mm | 1038 mm |
| Bottom Bracket Drop | 80 mm | 77 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 703 mm | 735 mm | 773 mm | 790 mm | 813 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 165 cm | 170 cm | 180 cm | 190 cm | 203 cm |
Model Overview
WI.DE. EKAR belongs to the Open Wide model. 7 bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
OPEN WI.DE. EKAR 2022 is the cheapest bike model and costs 6200$. OPEN WI.DE. Force/Eagle AXS ENVE 2022 is the most expensive one and costs 7600$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When OPEN released this model in 2022, its price was 6200$. In conclusion, this bike price is 151.83% higher than the price of the average Gravel bike.
WI.DE. EKAR components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When it comes to wheels, the WI.DE. EKAR bike is equipped with the 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. OPEN WI.DE. EKAR has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
