Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Altus, Shimano -
Suspension Rigid -
Motor Shimano 250W 60Nm mid-drive -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Meta 30 aluminum
Suspension Fork
Aluminum Tapered 1-1/2 to 1-1/8 inch
Drivetrain
Rear Derailleur
Shimano Altus Shadow
Front Derailleur
N/A
Shift Levers
Shimano Altus 9
Cassette
Shimano 11-32
Crank
Shimano STePS
Bottom Bracket
Shimano STePS E-6100
Chain
KMC E9S
Pedals
Wellgo flat
Wheels
Front Hub
Formula/Shimano
Rear Hub
Formula/Shimano
Rims
Weinmann U28 TL
Tires
Kenda Kwick Journey 700 x 42
Brakes
Brakes
Shimano BR-MT200 hydraulic disc
Brake Levers
Shimano BL-MT200
Cockpit
Stem
Opus Silver
Handlebar
Opus Bronze 25 mm rise
Headset
FSA Orbit integrated sealed
Seat
Saddle
Opus E-City with handle
Seatpost
Opus Silver 30.9 x 350/300
Motor & Battery
Motor
Shimano STePS motor E-6100 250W 60Nm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.49 mm | 1.47 mm |
| Stack | 629 mm | 629 mm | 638 mm |
| Reach | 406 mm | 421 mm | 433 mm |
| Top Tube Length | 596 mm | 611 mm | 626 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 145 mm | 145 mm | 155 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 486 mm | 486 mm | 486 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
CONNECT 6100 belongs to the Opus E Connect model. 8 e-bikes variations carry this model name so far. Take a sneak peek at all Opus E Connect e-bikes models from 2023, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Comfort e-bikes average price
If you want to purchase a solid Comfort e-bike, it is important to know that the average cost is 1957$. However, you could also get a good Comfort e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork material
When it comes to the fork, this e-bike has an aluminum one, which doesn’t add too much extra weight to the e-bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
When it comes to wheels, the CONNECT 6100 e-bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Opus CONNECT 6100 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Opus CONNECT 6100 e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
