Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Acera, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Meta 30 aluminum
Suspension Fork
Suntour NEX E-25 63 mm with lockout
Drivetrain
Rear Derailleur
Shimano Acera Shadow
Front Derailleur
N/A
Shift Levers
Shimano Acera 9
Cassette
Shimano 11-32
Crank
Shimano STePS
Bottom Bracket
Shimano STePS E-6100
Chain
KMC E9S
Pedals
Wellgo flat
Wheels
Front Hub
Formula/Shimano
Rear Hub
Formula/Shimano
Rims
Alex EM23
Tires
Kenda Kwick Journey 700 x 42
Brakes
Brakes
Shimano BR-MT201 hydraulic disc
Brake Levers
Shimano BL-MT201
Cockpit
Stem
Promax adjustable 110 mm
Handlebar
Opus Bronze 25 mm rise
Headset
FSA Orbit integrated sealed
Seat
Saddle
Opus E-Bike with handle
Seatpost
Opus Silver 30.9 x 350/300
Motor & Battery
Motor
Shimano STePS motor E-6100 250W 60Nm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.49 mm | 1.47 mm |
| Stack | 629 mm | 629 mm | 638 mm |
| Reach | 406 mm | 421 mm | 433 mm |
| Top Tube Length | 596 mm | 611 mm | 626 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 145 mm | 145 mm | 155 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 486 mm | 486 mm | 486 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
CONNECT LRT belongs to the Opus E Connect model. Opus released 8 e-bikes variations of this model so far. You can easily view all of the Opus E Connect e-bikes models from 2023, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Comfort e-bikes average price
According to our math, the average price for a trustworthy Comfort e-bike is 1957$. However, you could also get a good Comfort e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Average weight for Comfort e-bikes
Comfort e-bikes weigh an average of 24.41 kg (53.81 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
a bit lighter than average, CONNECT LRT has a weight of 22.41 kg (49.41 lbs). In other words, this model is 8.92% lighter than the average Comfort e-bike.
Overview of components
Fork
This e-bike has the Suntour NEX fork installed. The fork’s travel is 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
As for the wheels, Opus CONNECT LRT 2023, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Opus CONNECT LRT has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
