Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Alivio, Shimano -
Suspension Rigid -
Motor Shimano 250W 40Nm mid-drive -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Meta 30 aluminum
Suspension Fork
Aluminum tapered 1-1/2 to 1-1/8 in
Drivetrain
Rear Derailleur
Shimano Alivio 3100 Shadow
Front Derailleur
N/A
Shift Levers
Shimano Alivio 9
Cassette
Shimano 11-36
Crank
Shimano STePS
Bottom Bracket
Shimano STePS E-5000
Chain
KMC E9S
Pedals
FPD NW-247
Wheels
Front Hub
Formula/Shimano
Rear Hub
Formula/Shimano
Rims
Weinnman U32 TL
Tires
Kenda Kwick Seven.5 27.5 x 2.4
Brakes
Brakes
Shimano BR-MT201 hydraulic disc
Brake Levers
Shimano BL-MT201
Cockpit
Stem
Opus Silver
Handlebar
Opus Bronze 25 mm rise
Headset
FSA Orbit integrated sealed
Seat
Saddle
Opus E-CITY
Seatpost
Opus Silver 31.6 x 350
Motor & Battery
Motor
Shimano STePS motor E-5000 250W 40Nm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.5 mm | 1.47 mm |
| Stack | 571 mm | 586 mm | 606 mm |
| Reach | 371 mm | 391 mm | 411 mm |
| Top Tube Length | 536 mm | 566 mm | 597 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm |
| Bottom Bracket Drop | 65 mm | 60 mm | 60 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
EBIG CITY is part of the Opus E Ebig model. 10 e-bikes variations carry this model name so far. Take a sneak peek at all Opus E Ebig e-bikes models from 2023, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Commuter e-bikes
According to our calculations, the average cost of a Commuter e-bike that is reliable is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Average weight for Commuter e-bikes
On a deeper look, we notice that the average weight of a Commuter e-bike is 24.02 kg (52.95 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Opus EBIG CITY it’s weighing 19.78 kg (43.61 lbs). At this weight, is much lighter than average. To sum up, it’s 21.44% lighter than the average weight of Commuter e-bikes.
Overview of components
Fork material
When it comes to the fork, this e-bike has an aluminum one, so there won’t be much extra weight added to the e-bike. However, they are not so stiff as carbon forks are.
Wheels
As for the wheels, Opus EBIG CITY 2023, has a aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The EBIG CITY comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
EBIG CITY comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
