Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Apex -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Meta 30 aluminum
Suspension Fork
Full carbon tapered 1-1/2 to 1-1/8 in
Drivetrain
Rear Derailleur
SRAM APEX 1 long cage
Front Derailleur
N/A
Shift Levers
SRAM APEX 1x11
Cassette
SRAM PG1130 11-42
Crank
SRAM Apex 1
Bottom Bracket
SRAM GXP sealed BSC threaded
Chain
SRAM PC1110
Pedals
N/A
Wheels
Front Hub
Alex Bear Pawls through axle 12 mm fr/rr
Rear Hub
Alex Bear Pawls through axle 12 mm fr/rr
Rims
Weinmann U28TL 650
Tires
Kenda Flintridge Sport 650 x 45 CSK
Brakes
Brakes
Promax Decode R Flat Mount twin piston disc
Brake Levers
SRAM
Cockpit
Stem
Promax
Handlebar
X-Race Aero 16° flare
Headset
FSA Orbit integrated sealed
Seat
Saddle
Opus Endurance
Seatpost
Promax alloy 27.2 x 300
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.51 mm | 1.54 mm | 1.56 mm | 1.58 mm |
| Stack | 552 mm | 571 mm | 589 mm | 609 mm | 629 mm |
| Reach | 375 mm | 379 mm | 383 mm | 391 mm | 399 mm |
| Top Tube Length | 529 mm | 543 mm | 558 mm | 577 mm | 598 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 545 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 133 mm | 153 mm | 173 mm | 193 mm | 213 mm |
| Chainstay Length | 424 mm | 426 mm | 426 mm | 428 mm | 428 mm |
| Bottom Bracket Drop | 78 mm | 76 mm | 74 mm | 73 mm | 72 mm |
| Standover Height | 742 mm | 765 mm | 790 mm | 817 mm | 846 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
HORIZON AL APEX 1 650 is part of the Opus Horizon model. 13 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Gravel bikes average weight
Gravel bikes have an average weight of 8.13 kg (17.92 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Opus HORIZON AL APEX 1 650 it’s weighing 10.16 kg (22.4 lbs). At this weight, is much heavier than average. In short, the average Gravel bike weight is 24.97% lower than this one.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The HORIZON AL APEX 1 650 2023 bike is equipped with aluminum wheels when leaving the factory. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The HORIZON AL APEX 1 650 has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Opus HORIZON AL APEX 1 650 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
