Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 200mm -
Travel Rear 200mm -
Fork Fox Factory Float 40
-
Groupset X01 -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Factory 40, Grip 2 damper
Rear Shock
FOX Float X2 Factory, 250x75mm
Drivetrain
Rear Derailleur
SRAM X01 DH, 7-speed
Front Derailleur
None
Shift Levers
SRAM X01 DH, 7-speed
Cassette
SRAM XG-795 DH, 7-speed, 10-24 tooth
Crank
SRAM X01 DH
Bottom Bracket
SRAM GXP
Chain
SRAM PC-1110
Chain Guide
MRP G4
Pedals
None
Wheels
Front Hub
Hope Pro 4
Rear Hub
Hope Pro 4
Rims
Stans Flow Mk3
Tires
Schwalbe Magic Mary 27.5x2.35", Super Gravity
Brakes
Brakes
Shimano Saint, 203mm rotors
Brake Levers
Shimano Saint
Cockpit
Stem
Renthal Integra, 50mm
Handlebar
Renthal Fatbar Carbon, 800mm, 20mm rise, 35mm diameter
Grips
Strange 130 Lock-on
Headset
Hope for 1.1/8" steerer, black
Seat
Saddle
SDG I-Fly, I-Beam
Seatpost
SDG I-Beam, aluminium
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.43 mm | 1.39 mm | 1.33 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Stack | 628 mm | 628 mm | 628 mm | 628 mm |
| Reach | 419 mm | 439 mm | 453 mm | 473 mm |
| Top Tube Length | 598 mm | 618 mm | 632 mm | 652 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 381 mm | 431.8 mm | 431.8 mm |
| Head Tube Angle | 63 ° | 63 ° | 63 ° | 63 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1238 mm | 1259 mm | 1273 mm | 1293 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 723 mm | 723 mm | 738 mm | 738 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
327 Factory is part of the Orange 327 model. There are 4 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Downhill bikes average price
If you want to purchase a solid Downhill bike, it is important to know that the average cost is 3391$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Downhill bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
327 Factory components
Fork
Orange 327 Factory 2019 bike is equipped with the Fox Factory Float 40 fork, and has 200mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the FOX Float X2 Factory model, with a travel of 200mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
As for the wheels, Orange 327 Factory 2019, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The 327 Factory has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
